Hubbell HBL2721 30A 3Ph 250V AC Twist-Lock INSULGRIP Black Nylon Plug

Manufacturer: Hubbell / Kellems | Catalog # HBL2721 | North Coast Part # 10689
$100.53/ea
Log in or register to view your price, purchase history, and more!
17 available

For Pick Up

at Auburn Closes 4:00pm PT
17 available

For Delivery

Order by 4:00pm PT for delivery tomorrow
Not in local stock *
Check another branch
Specification Sheet Brochure Product Catalog Page Installation / Instruction Manual
Locking Devices, Twist-Lock®, Industrial, Male Plug, 30A 3-Phase 250V AC, 3-Pole 4-Wire Grounding, L15-30P, Screw Terminal, Black and White.

Technical Information

Amperage
30 Amp
Applications
Extra Heavy Duty Industrial Application
Conductor Size
12-8 AWG
Cord Type
Portable
Current
30 Amp
Grounding
Yes
Horsepower
3 hp
Material
Composite
Mounting Type
Surface
NEMA
L15-30P
Number of Phases
3 Phase
Number of Poles
3 Pole
Number of Wires
4 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA C22.2 No.42,Fed.Spec. W-C-596,UL 498
TC Connection
Pressure Screw Terminal
Type
Insulgrip, Standard Sized
Voltage
250 Volt
Wattage
7500 Watt
Wire Count
4
Wire Size
16-8 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®, Insulgrip®

General Product Info

12-Digit UPC
783585039220
Color
Black,White
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
GTiN
00783585039220
Product UPC
78358503922
Weight
0.25 lb

Dimensions

Height
2-3/4 Inch
Length
2.33 Inch
Width
2.33 in

Certifications and Compliance

Country of Origin
USA
Features
  • Superior cord grip design protects terminations from excess strain.
  • Clear, funnel shaped wire entry for ease of termination.
  • Integral dust shield protects wiring chamber from dust or contaminants.
  • Standard Product
