Blackburn 32005BD Lock-Tite Lug

Manufacturer: Thomas & Betts / Blackburn | Catalog # 32005BD | North Coast Part # 111993
$28,872.19/c (100 ea)
ea
Order in multiples of 10 (pack qty)
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
Locktite Copper Double-Barrel Lug for Conductor Range 8-4 AWG

Technical Information

Applications
For Copper Conductors
Conductor Size
8-4 AWG Main/Primary
Conductor Type
Copper
Material
Copper
Mounting Hole Size
1/4 in
Standard
UL E9809
Type
Double Barrel
Voltage
600 Volt

Manufacturer Information

Brand
Thomas & Betts (T&B)
Sub Brand
Blackburn®, Locktite®

General Product Info

12-Digit UPC
786210839400
GTiN
00786210839400
Product UPC
78621083940
Features
  • Easy installation. High conductivity. Wide cable range.
  • Screw tightening. Serrated saddle. Built-in lockwasher.
Notes
  • With Filister Head Screw.
