Product image for Hoffman CTD424212 CONCEPT Two-Door Enclosures, 42" x 42" x 12", Gray, Steel
Email

Hoffman CTD424212 CONCEPT Two-Door Enclosures, 42" x 42" x 12", Gray, Steel

Manufacturer: nVent Hoffman | Catalog # CTD424212 | North Coast Part # 1146681
$2,237.93/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
Concept Enclosures are ideal for machine control applications. With streamlined styling, flush quarter-turn latches and an attractive, durable finish. Two-door landscape models provide full-width access and easy panel installation.

Technical Information

Applications
For Industrial, Machine Control Applications
Body Gauge
14
Body Thickness
1.9 mm
Color Coding
ANSI 61
Cover Type
3-Point Latch, Concealed Hinged
Door Gauge
14
Gauge
14
IP Rating
55
Material
Steel
Mounting Type
Wall
Size
42.00x42.00x12.00 in
Standard
CSA, File No. 42186, Type 12,CUL Listed Per CSA C22.2 No. 94; Type 12; File No. E61997,IEC 60529, IP55,NEMA/EEMAC Type 12,UL 508A Listed; Type 12; File No. E61997,VDE IP 55
Type
Two Door

Manufacturer Information

Brand
nVent Hoffman
Sub Brand
Concept

General Product Info

12-Digit UPC
783510294472
Color
ANSI 61 Gray
Finish
Powder Coated
GTiN
00783510294472
Product UPC
78351029447
Weight
133 lb

Dimensions

Depth
12 Inch
Height
42 Inch
Length
46-3/4 Inch
Width
42 in
Features
  • Seams continuously welded and ground smooth
  • Corner-formed doors
  • Simple easy-to-remove and install hinge pins with built-in captivation clip
  • High-torque threadless studs and fasteners on door
  • Minimum-width body flange provides maximum door opening (210 degrees)
  • Door opens 210 degrees
  • External formed body flange
  • Panel mounting studs fit optional Concept panels and other accessories
  • Mounting holes in back of body for optional external wall-mount brackets
  • Removable door with hidden hinges for clean, aesthetic appearance
  • Seamless foam-in-place gasket
  • Quarter-turn slotted latch(es)
  • Door alignment device on doors wider than 30 in.
  • Four hinges on 60in.-high enclosures
  • Grounding stud on body; bonding provision on door
  • Provisions on door for optional high-impact thermoplastic data pocket
  • Hardware kit with panel mounting nuts, panel grounding hardware and sealing washers
  • Installation instructions provided
  • Overlapping door design that provides full-width access
  • Three-point latch system on right-hand hinged door furnished with flush slotted insert
