Pass & Seymour CO1110 8 x 10 Video/Voice Combination Module with RJ31X

Manufacturer: Legrand / Pass & Seymour | Catalog # CO1110 | North Coast Part # 1267452
$119.08/ea
ea
Log in or register to view your price, purchase history, and more!
7 available

For Pick Up

at Auburn Closes 3:00pm PT
7 available

For Delivery

Order by 4:00pm PT for delivery tomorrow
Not in local stock *
Check another branch
Specification Sheet Installation / Instruction Manual CAD Drawing #1
The 10x8 combo distributes up to four telephone lines to ten network locations, and one digital video line to eight locations from a cable company approved Antronix splitter. This module also provides RJ31X line seizure port for home security system configuration.

Technical Information

Cable Type
Cat 5,Cat 5e,Cat 6,Coaxial
Impedance
75 ?
Material
Steel
Mounting Type
Enclosure
Temperature Rating
-40 degrees C to 60 degrees C
Type
Telecom/Video Module

Manufacturer Information

Brand
Legrand
Sub Brand
On-Q

General Product Info

12-Digit UPC
804428066880
Color
Black
GTiN
00804428066880
Product UPC
80442806688
UNSPSC
43222819
Weight
1.53 lb

Dimensions

Height
5 Inch
Length
3.1 Inch
Width
6 in

Certifications and Compliance

Certifications
ROHS,UL
Country of Origin
China
Certifications
  • UL Listed
  • RoHS Compliant
Features
  • Includes an MDU Mounting Bracket (AC1042), an 8-way 2 GHz Video Splitter (VM0208), 6-way Phone Module (TM0106) and 6-way Cat 5e Data Board (AC0506)
  • Four telephone lines can be split 10-ways via 110 Punch-down terminations
  • Coaxial splitter is compatible with networks such as VoIP and DOCSIS 3.0
  • RJ31X line seizure port prioritizes security system operations
  • Corrosion-resistant mounting infrastructure included
  • 6 kV Ring wave surge protection on all coax ports
