Product image for Hubbell HBL8432C 30 Amp 3-Phase 250 VAC 3-Pole 4-Wire NEMA 15-30P Black Nylon Straight Blade Plug
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Hubbell HBL8432C 30 Amp 3-Phase 250 VAC 3-Pole 4-Wire NEMA 15-30P Black Nylon Straight Blade Plug

Manufacturer: Hubbell / Kellems | Catalog # HBL8432C | North Coast Part # 133198
$179.00/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, Plug Industrial Grade, 3-Pole 4-Wire Grounding, 30A 3 Phase 250V AC, 15-30P, Single Pack.

Technical Information

Amperage
30 Amp
Applications
Industrial/Commercial
Conductor Size
12-4 AWG
Cord Type
All Portable
Current
30 Amp
Grounding
Grounding
Material
Composite
Mounting Type
Cord
NEMA
15-30P
Number of Phases
3 Phase
Number of Poles
3 Pole
Number of Wires
4 Wire
Size
Standard Sized
Standard
CSA,File E1706,UL
TC Connection
Terminal Screws
Type
Insulgrip, Right-angled
Voltage
250 Volt
Wattage
7.5 kW
Wire Count
4
Wire Size
12-4 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade Devices

General Product Info

12-Digit UPC
783585015415
Color
Black,White
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
GTiN
00783585015415
Product UPC
78358501541
Weight
0.85 lb

Dimensions

Height
3.418 Inch
Length
5.168 Inch
Width
3.300 in

Certifications and Compliance

Country of Origin
USA
Features
  • Catalog number, ratings and certifications molded in face
  • Gripping ribs provide secure gripping area
  • Supertough nylon housing
