Hubbell Wiring Devices HBL1223R 20 Amp 120/277 VAC 3-Way Red Toggle Switch

Manufacturer: Hubbell / Kellems | Catalog # HBL1223R | North Coast Part # 14266
$38.85/ea
ea
Adding...
Log in or register to view your price, purchase history, and more!
Usually ships within 6 to 8 days
Specification Sheet Product Catalog Page Installation Instructions
Switches and Lighting Controls, Extra Heavy Duty Industrial Grade, Toggle Switches, General Purpose AC, Three Way, 20A 120/277V AC, Back and Side Wired, Red Toggle

Technical Information

Action
Positive Snap
Actuator
Toggle, Rocker/Button
Amperage
20 Amp
Applications
Back and Side Wired
Contact Configuration
Two Position
Contact Rating
Per UL 20
Current
20 Amp
Enclosure
None
Grade
Industrial
Material
Thermoplastic
Number of Poles
1 Pole
Operating Cycles
50000
Operating Temperature
Maximum continuous 75C and minimum -40C without Impact
Size
4.06 in x 1.31 in x 1.87 in
Standard
UL
TC Connection
Back and Side Wired
Type
General Purpose, 2 Position, 3 Way, Standard, Extra Heavy Duty
Voltage
120-277 Volt
Wattage
5540 Watt
Wire Size
14-10 AWG

Manufacturer Information

Family Brand Name
Hubbell Wiring Device Kellems
Sub Brand
AC Toggle Switches

General Product Info

Color
Red
Environmental Conditions
Indoor Dry unless protected by additional means
GTiN
00783585431987
Product Series
Extra Heavy Duty
Product UPC
78358543198
Weight
0.2 lb

Dimensions

Height
1.66 Inch
Length
4.06 Inch
Width
1.31 in

Certifications and Compliance

Country of Origin
China
  • Strip gauge for accurate wiring
  • Large brass binding head screws with deep slots
  • Abuse resistant nylon toggle
