Product image for Hoffman LHC236016 230 x 600 x 155mm INLINE Landscape Wall-Mount Enclosure w/ Hinged Solid Door, Type 4/12, Steel
Email

Hoffman LHC236016 230 x 600 x 155mm INLINE Landscape Wall-Mount Enclosure w/ Hinged Solid Door, Type 4/12, Steel

Manufacturer: nVent Hoffman | Catalog # LHC236016 | North Coast Part # 149235
$306.18/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
When applications require mounting electrical components the full width of an enclosure, the landscape orientation of this aesthetic InLine Enclosure makes it possible. Full-width mounting brackets can be drilled anywhere along their length, providing maximum mounting flexibility.

Technical Information

Applications
Controls and Drives
Color Coding
RAL 7035
Cover Type
Hinged with Quarter-Turn Latches
IP Rating
66
Material
Steel
Mounting Type
Wall, Flush
Size
230x600x155mm
Type
Landscape, Two Lock, Single Door

Manufacturer Information

Brand
nVent Hoffman
Sub Brand
Inline™

General Product Info

12-Digit UPC
783510110260
Color
7035 Light Gray
Finish
Powder Coated
GTiN
00783510110260
Product UPC
78351011026
Weight
17.3 lb

Dimensions

Depth
155 mm
Height
230 mm
Length
24.4 Inch
Thickness
1.5 mm
Width
600 mm
Features
  • Metric dimensions
  • Seams continuously welded and ground smooth
  • External formed body flange channels away liquids
  • Large perimeter body opening
  • External welded-on mounting brackets for easy installation
  • Bonding provision on cover and door
  • Hardware kit includes panel mounting screws and grounding hardware
  • Removable hinged door
  • Self-grounding, slotted quarter-turn latches
  • Door opens 180 degrees
  • Window door models include flush-mounted 4.8-mm (3/16-in.) clear polycarbonate window
  • Seamless foam-in-place gasket
