Red Dot 2IHD5-1 2-Gang Weatherproof Metallic Device Box, (5) 1/2" Hubs, 2-5/8" Deep

Manufacturer: Thomas & Betts / Red Dot | Catalog # 2IHD5-1 | North Coast Part # 153425
$6,366.36/c (100 ea)
Log in or register to view your price, purchase history, and more!
0

Not Available for Pickup at Auburn Closes 3:00pm PT
0 available

For Delivery

Not in local stock *
Check another branch
*Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
Two Gang Deep Universal Weatherproof Box, 40.3 Cubic Inches, Hub Size 1/2 Inch, Silver, Aluminum, 5 Outlets with 2 on Top and Bottom and 1 on Back

Technical Information

Applications
Dry-Tite Boxes and Covers Protect Wiring Devices, Switches, Electronic Components and Terminal Blocks in Dry, Damp and Wet Locations
Cable Entry
(5) 1/2 in Hub
Material
Aluminum
Number of Gangs
2 Gang
Number of Outlets
5
Standard
UL E28688
Type
Single, 5-Outlet, Rectangular

Manufacturer Information

Brand
ABB
Sub Brand
Red Dot®

General Product Info

12-Digit UPC
042269393615
Color
Silver
Finish
Powder Coated
GTiN
00042269393615
Product UPC
04226939361

Dimensions

Height
5.3 Inch
Width
5.2 in
Features
  • Clean cover edges provide good gasket sealing.
  • Clear UL and cubic content markings speed approval by inspectors
  • Securely fastened mounting plates reduce costly call backs
  • Convenient mounting lugs for a variety of mounting methods
  • Alloy A380 aluminum, certified zinc alloy and stainless steel springs provide increased corrosion resistance
  • Die Cast construction and industrial design combine to produce a rugged protective enclosure for devices.
  • Precision cast and machined surfaces permit safer wire pulling.
Notes
  • Rain tight when used with appropriate Red Dot covers.
Application
  • Dry-tite boxes and covers protect wiring devices, switches, electronic components and terminal blocks in dry, damp and wet locations
  • Junction box for branch conduits
  • Accessible wiring chamber provides a convenient location to maintain or change a system, pull conductors and make splices
Certifications
  • UL
