Hubbell Wiring Devices HBL123 3/4 Hp 10 Amp 250 VAC SPDT Panel Mount Screw Terminal Bat Handle Heavy Duty Switch

Manufacturer: Hubbell / Kellems | Catalog # HBL123 | North Coast Part # 160395
$10.01/ea
ea
Adding...
Log in or register to view your price, purchase history, and more!
Usually ships within 6 to 8 days
Specification Sheet Product Catalog Page
Switches and Lighting Controls, Commercial Grade, Panel Mount and Specialty Switches, Bat Handle Switches, Single Pole Double Throw Center Off, 10A 250V/10A 125V,

Technical Information

Actuator
Toggle
Applications
On/Off/On
Contact Configuration
Two Position
Contact Rating
As Indicated
Current
10/20 A
Grade
Commercial
Indicator
Comes with Indicator Plate
Interrupt Rating
10A 250V AC, 20A 125V AC
Material
Metal
Number of Poles
1 Pole
Operating Temperature
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Size
Standard Sized
Standard
UL
TC Connection
Screw Terminal
Type
Bat Handle
Voltage
10A 250, 20A 125 Volt
Wattage
2500 Watt

Manufacturer Information

Family Brand Name
Hubbell Wiring Device Kellems
Sub Brand
Panel Mount Switches

General Product Info

Color
Chrome
GTiN
00783585016764
Product Series
Single Pole/Double Throw
Product UPC
78358501676
Weight
0.05 lb

Dimensions

Height
0.8 Inch
Length
2.15 Inch
Width
0.56 in

Certifications and Compliance

Country of Origin
China
  • Nickel Plated for Corrosion Resistance
