Siemens 52PP2W2AP 30 mm 1NO 1NC 2-Position Maintained Metal Bezel Non-Illuminated Push Button

Manufacturer: Siemens | Catalog # 52PP2W2AP | North Coast Part # 1732014
$318.85/ea
ea
Log in or register to view your price, purchase history, and more!
0

Not Available for Pickup at Auburn Opens Thursday 4:00am PT
0 available

For Delivery

Not in local stock *
Check another branch
*Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
30mm command/52, chrome finish heavy duty,watertight/oiltight point-of-purchase kit push-pull operator non-illuminated mushroom head cap small 1 3/4 (44.5 mm) plastic cap, red 2 position maintained, pull-to-release with 1 n.o. - 1 n.c. heavy duty

Technical Information

Action
DP
Actuator
Pushbutton
Amperage
10 Amp
Applications
Use with magnetic controllers to control the starting, and stopping of motors. Open type devices are designed for mounting in sheet metal enclosures or for mounting on flush plates.
Contact Configuration
1NO-1NC
Contact Rating
A600 / P600
Number of Poles
2 Pole
Operating Cycles
300k
Operating Temperature
-35 to +70degrees C (-31 to +158degrees F)
Size
30 mm Pilot Device
Type
Non-Illuminated
Voltage
600 Volt

Manufacturer Information

Brand
Siemens
Sub Brand
Command/52

General Product Info

12-Digit UPC
662643526844
GTiN
00662643526844
Product UPC
66264352684
Weight
0.600 lb

Dimensions

Height
3-1/4 Inch
Length
5.55 Inch
Width
6.950 in

Certifications and Compliance

Country of Origin
Mexico
