Product image for Hoffman APWK1711NFSS Steel, Stainless Steel and Non-Metallic Window Kits, 19.5" x 13.5" x.31", SS Type 304
Email

Hoffman APWK1711NFSS Steel, Stainless Steel and Non-Metallic Window Kits, 19.5" x 13.5" x.31", SS Type 304

Manufacturer: nVent Hoffman | Catalog # APWK1711NFSS | North Coast Part # 17387
$1,076.01/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
All Window kits are easy to install and require a simple rectangular enclosure cut-out. They are ideal for indoor and outdoor Type 3R, 4 and 12 applications. Stainless Steel Window Kits are ideal for indoor and outdoor Type 3R, 4X and 12 applications where corrosion is a concern. Non-Metallic Window Kits are ideal for indoor and outdoor Type 3R, 4, 4X and 12 applications. They are also ideal for non-metallic enclosures where exterior metallic materials are not allowed and can accommodate up to .25-in. enclosure material thickness. When determining if a window kit will fit in a door or cover, be sure to allow for gaskets, data pockets, door handles, latch rods and other parts attached to the door or cover.

Technical Information

Applications
Indoor or Outdoor Applications
Enclosure Rating
4, 4X, 12, 13, IP66
Enclosure Type
NEMA 4, 4X, 12, 13, IP66
Material
Steel
Size
19.50x13.50x.31 in
Standard
12,13,4X (stainless Steel Version Only),CSA Type 4,File No. 42186,File No. E61997,IEC 60529,IP66,NEMA/EEMAC 4,Type 4,UL 508A Component Recognized
Type
Window Kits

Manufacturer Information

Brand
nVent Hoffman
Sub Brand
Hoffman

General Product Info

12-Digit UPC
783510220600
Color
Gray
Finish
Brushed
GTiN
00783510220600
Product UPC
78351022060
Weight
6.9 lb

Dimensions

Depth
27 mm
Height
2.3 Inch
Length
495 mm
Thickness
1.98 mm
Width
343 mm
Features
  • Window kits of the same size use the same interchangeable cut-out
  • The gasket material on all windows is resistant to oils, cutting fluids and many other liquids
  • All required hardware is furnished, along with assembly and cut- out instructions
  • The clear window of the Steel and Stainless Steel Window Kit is made of .25-in. (6mm) impact-resistant polycarbonate material
  • Non-Metallic Window kit are made of a single piece polycarbonate material
