Product image for RAB W34-30L 30W LED Wall Pack, 3500 Lumens, 5000K 80CRI, 120-277V, 0-10V Dimming, Bronze Finish
Image thumbnail 0
Image thumbnail 1
Email

RAB W34-30L 30W LED Wall Pack, 3500 Lumens, 5000K 80CRI, 120-277V, 0-10V Dimming, Bronze Finish

Manufacturer: RAB Lighting | Catalog # W34-30L | North Coast Part # 1753385
$169.92/ea
ea
Log in or register to view your price, purchase history, and more!
0

Not Available for Pickup at Auburn Closes 3:00pm PT
0 available

For Delivery

Not in local stock *
Check another branch
*Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
W34 Wallpack 30W,3100Lm LED, 120-277V, 5000k, 80 CRI, Bronze

Technical Information

Ambient Temperature
104 degrees F
Amperage
0.12 Amp
Average Rated Life
50,000 hr
Color Accuracy
84
Color Rendering Index
84
Color Temperature
5000 K
Correlated Color Temp
5,000 K
Efficacy
123 LPW
Input Wattage
29 W
Lens Material
Glass
Lumens
3,604 Lumen
Max Operating Temperature
104 degrees F
Minimum Starting Temp
-40 degrees C
Power Factor
120 V
Total Harmonic Distortion
5.2% At 277V,7.5% At 120V
Type
Constant Current
Voltage
120/277 Volt
Wattage
30 Watt

Manufacturer Information

Brand
Rab Design Lighting

General Product Info

12-Digit UPC
019813833118
GTiN
00019813833118
Product UPC
01981383311
Weight
7.2 lb
Features
  • Economy-grade wall pack with traditional look
  • Covers footprint of small HID wall packs
  • Available in various lumen packages
  • Integrated 0-10V dimming
  • 50,000-Hour LED lifespan
  • Replacement
  • Equivalency
  • 5 Yr Limited Warranty
  • Trade Agreements Act Compliant
  • Buy American Act Compliance
