Burndy YA27LNT38 3/0 AWG CU, One Hole, 3/8 Standard Barrel, Inspection Window, Narrow Tongue Internal Chamfer, Tin Plated, UL/CSA, 90.C, Up to 35kV, ORANGE Color Code, 14 Die Index

Manufacturer: Burndy | Catalog # YA27LNT38 | North Coast Part # 189739
$13.88/ea
ea
Log in or register to view your price, purchase history, and more!
0

Not Available for Pickup at Auburn Opens Friday 5:00am PT
0 available

For Delivery

Not in local stock *
Check another branch
*Next Day Delivery not avail / contact sales for lead times & return policy
Buy American Compliant Buy American Compliant Specification Sheet
Flex Conductor Standard Barrel Narrow, 3/0 AWG, 3/8 in, 2.73 in L.

Technical Information

Applications
For Code Conductor
Cable Size
3/0 AWG
Color Coding
Orange
Conductor Size
2/0 AWG
Connection Type
Terminal
Material
Copper
Max Voltage
35000 V
Number of Holes
1 Hole
Plated?
Yes
Plating Type
Tin - Electro Plated
Stud Size
0.375 in
Type
YA-L-NT, Code Conductor Standard Barrel Narrow Tongue
Voltage
35,000 Volt

Manufacturer Information

Brand
Burndy
Sub Brand
HYLUG

General Product Info

12-Digit UPC
781810018538
Finish
Tin Plated
GTiN
00781810018538
Product UPC
78181001853

Dimensions

Height
0.62 Inch
Length
2.64 Inch
Overall Length
2.64 in
Width
0.76 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
CSA
Yes
  • UL Listed 90 DEG C, 600 V - 35 KV, 45 DEG And 90 DEG Angles Are Available, Temperature Rating: 90 DEG C, Tongue Angle: Straight, Die Index: 14, Wire Strip Length: 1-1/16 IN, Finish: Electro-Tin Plated, Tools, Die Set Catalog Number, And (number Of Crimps): Mechanical: MD6, OUR840, MD7-34R Tool, W27VT Die, (2), Hydraulic: BCT500HS, Y500CTHS Tool, X27RT Die, (3), Y35, Y39, Y750, PAT750 Tool, U27RT Die, (1), Y46 Tool, U27RT Die With PUADP-1 Adapter, (1), Color Code: Orange, Conductor Type: Commercial Stranded Copper, Dieless Tools (number Of Crimps): Y644HS Tool, (1), Y81KFT, Y81KFTMBH, PAT81KFT-18V Tool, (2)
