Erico EGBA14430BB Grounding Busbar, w/Insulators and Brackets, BB, 30" x 4" x 0.25"

Manufacturer: Cadweld | Catalog # EGBA14430BB | North Coast Part # 2406754
$997.44/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet Brochure Product Catalog Page
Proper bonding is essential to create an equipotential plane between service grounds and equipment during fault and transient conditions. This equipotential plane provides a near-zero voltage differential, and serves to protect people and equipment during these events. The grounding busbar is the most popular bonding product in use today.

Technical Information

Material
Copper
Pigtail Included
No
Tin Plating
No

Packaging

Standard Packaging Qty
1 pc

Manufacturer Information

Brand
nVent Erico

General Product Info

12-Digit UPC
782856697503
GTiN
00782856697503
Product UPC
78285669750
Weight
4.24 kg

Dimensions

Length
30 Inch
Thickness
1/4 in
Width
4 in

Certifications and Compliance

Certifications
CULus
Features
  • Provides a convenient, single-point grounding and bonding location
  • Conductors are welded to the bar using a nVent ERICO Cadweld exothermic connection or are mechanically fastened by using lugs
  • Custom bars can be designed and manufactured to customer specifications
Certifications
  • cUL CSA C22.2 No. 41
  • UL ANSI/UL 467
