Hoffman N431226G150 12000BTU 230V Low Ambient / Heater

Manufacturer: nVent Hoffman | Catalog # N431226G150 | North Coast Part # 2411580
$10,535.12/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
SpectraCool Narrow Indoor/Outdoor Air Conditioners provide the same broad spectrum of cooling capacity and options and the SpectraCool Indoor/Outdoor units in a more narrow, space-saving solution for low-depth cabinet needs. Narrow models are designed to fit on 12-inch (300-mm) deep floor- and wall-mount enclosures.

Technical Information

Applications
Controls and Drives; Power Distribution
BTU Hour
11000 BTU
Color Coding
RAL 7035
Material
Steel
Max Current
9.1 A
Max Temperature
131 degrees F
Min Temperature
-40 degrees F
Standard
CE,IP 34 On External Loop,IP 56 Internal Loop,Telcordia GR-487 Capable (Outdoor),UL/cUL Listed; Type 12, 3R, 4; 4X Optional; File No. SA6453
Type
Air Conditioners
Voltage
230
Wattage
3223 Watt

Manufacturer Information

Brand
nVent Hoffman
Sub Brand
SpectraCool

General Product Info

12-Digit UPC
783510238933
Color
Lt Gray
Finish
Powder Coated
GTiN
00783510238933
Product UPC
78351023893
Weight
138 lb

Dimensions

Depth
14 Inch
Height
43 Inch
Length
18 Inch
Thickness
1.21 mm
Width
11.5 in
Features
  • Narrow design accommodates 12-inch (300-mm) deep cabinets
  • Level 1 Protection Includes: Protective coatings only applied to copper tubing and coils on the condenser (exterior facing) side as well as thermostat coatings
  • Attractive industrial design with minimal use of visible fasteners
  • Level 2 Protection Include: Everything that was coated in Level 1, plus protective coatings applied to the evaporator (interior facing ) side and an additional wrap around the thermostat
  • Cleanable, reusable aluminum mesh filter protects coils for maximum cooling performance
  • Narrow design accommodates 12-inch deep cabinets
  • R407C, R513A or R134a refrigerants
  • Models for 115, 230 and 400/460 3-phase VAC power input
  • Outdoor model operating temperature range from -40 F/-40 C to 131 F/55 C (125 F/52 C on N28 Series)
  • Reliable mechanical thermostat on enclosure side of the unit; indoor air conditioner models include digital display on ambient side
  • Energy efficient rotary compressor on N36 and N43 models
  • Dust-resistant condenser coil allows the unit to be run filterless in most applications
  • Galvanized sheet-metal cover for rugged factory and outdoor environments
