SATCO 65/637 LED WIDE BEAM ANGLE CA

Manufacturer: Satco | Catalog # 65/637 | North Coast Part # 2425102

$292.36/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
CA Prop65 Warning CA Prop65 Warning Specification Sheet
SATCO|NUVO's 65-637 LED Wide Beam Angle Canopy, offers cutting-edge field-selectable capabilities. Tailor your lighting experience by selecting from three color temperatures (3K, 4K, 5K) and three wattage options (60W, 75W, 90W.) The canopy comes in a sleek bronze finish and boasts a surge protection of 2.5kV, ensuring enhanced durability. The integrated sensor port makes the installation of optional motion sensors, sold separately, a breeze. Additionally, the canopy is designed with an IK10 rated vandal-resistant lens to withstand damage, and it proudly carries an IP65 rating, safeguarding against harsh elements in even the most demanding environments.

Technical Information

Applications
Recessed Commercial; Recessed Residential; Damp Location; Wet Location Outdoor Rated Lamps
Average Rated Life
50000 hr
Beam Spread
190
Color Temperature
Warm White To Natural Light
Correlated Color Temp
3000 K
Dimmable?
Yes
Incandescent Equivalent
300 W
Indoor Outdoor
Outdoor
IP Rating
IP65
Lamp Type
LED
Lens Material
Polycarbonate
Lumens
12,557 Lumen
Material
Plastic
Number of Lamps
1
Operating Temperature
-40 degrees C
Power Factor
0.9
Standard
CSA C22.2 No. 85,UL E23018,cULus
Style
IS/IA Industrial Strip
Technology Type
LED
Type
Cable and Canopy Kit
Voltage
120 Volt
Wattage
60 Watt
Wet Location
Wet

Packaging

Pkg Qty
1

Manufacturer Information

Brand
Satco
Sub Brand
Satco

General Product Info

12-Digit UPC
045923654206
Color
Bronze
Finish
Bronze
GTiN
00045923654206
Product UPC
04592365420
Weight
5.06 lb

Dimensions

Height
3.62 Inch
Length
9.57 Inch
Warranty Length
5 yr
Width
9.57 in

Certifications and Compliance

CA Prop65 Warning
Lead
Country of Origin
Vietnam
Features
  • Wide Beam Angle for Broad Light Coverage
  • 3 CCT Selectable
  • 3 Wattage Selectable
  • Integrated Sensor Port
  • IK10 Vandal Resistant Lens
  • EM Battery Backup Capable
  • 0-10V Dimmable
  • 2.5kV Built-in Surge Protection
  • Bronze Finish
  • L:9.57 inches W:9.57 inches H:3.62 inches
  • Recommended Mounting Height: 15 to 20 Feet
Installation Notes
  • Hinged door for ease of installation
Prop 65
  • Lead
Accessory Products
  • 65-633
  • 86-217
  • 86-218
  • 86-219
  • 86-220
  • IP710-LFZ
  • DS710-10Z
  • SF10P
  • DF10P
  • DVSTV
  • DVSCSTV
  • MS-Z101
  • MS-Z101-V
  • NTSTV-DV
  • ADPD4FBL3P2W4
  • RMJS-8T-DV-B + PJ2-3BRL-GWH-L01
