Product image for AFC 1409N32-00 10-4 Solid (Black, Red, Blue, White) AC-90® Interlocked Galvanized Steel Armor, 125ft Coil
Image thumbnail 0
Image thumbnail 1
Email

AFC 1409N32-00 10-4 Solid (Black, Red, Blue, White) AC-90® Interlocked Galvanized Steel Armor, 125ft Coil

Manufacturer: AFC MC Cable | Catalog # 1409N32-00 | North Coast Part # 2454764
*Call For Price*
ea
Order in multiples of 5000 (pack qty)
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Buy American Compliant Buy American Compliant Specification Sheet MDM Safety Data Sheet
AC-90® Cables from Atkore, sometimes referred to as BX cable, are a commercial wiring method favored by installers for their flexible interlocked steel armor, which provides mechanical protection. These versatile 600V cables with THHN conductors have certain construction limitations due to the inception and design of UL Standard 4 over 100 years ago. The UL Standard allows for 2, 3, or 4 conductors, individually wrapped with moisture-resistant, fire-retardant paper and twisted from 14 AWG to 1 AWG. Type AC Cable is the foundation of all interlocked armored cable assemblies we have today.

Technical Information

Conductor Material
Copper
Conductor Size
10 AWG
Number of Conductors
4
Standard
CSA,E2186,UL
Type
AC-90® Steel Armored Cable Type AC

Manufacturer Information

Brand
AFC Cable Systems|Kaf-Tech
Sub Brand
AC-90®

General Product Info

12-Digit UPC
077680201904
GTiN
00077680201904
Product UPC
07768020190

Dimensions

Length
125 Foot

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
Features
  • Cable System. Technically equivalent and economically superior to traditional raceway and wire installations.
  • ColorSpec® ID/Color-Trak ID System. Black galvanized steel armor with phase ID painted directly onto the armor for added identification without the added step of opening the panel to determine circuit type.
  • Grounding. Armor in conjunction with the 16AWG aluminum ground/bonding conductor serves as equipment ground fault path.
  • Made in USA of US and/or imported materials
