Hubbell HBL4795 Locking COMB DUP Receptacle NEMA 5&L5-15R, 2H2N

Manufacturer: Hubbell / Kellems | Catalog # HBL4795 | North Coast Part # 27282
$105.20/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet Product Catalog Page Installation / Instruction Manual
Locking Devices, Twist-Lock®, Industrial, Combination Face Duplex Receptacle, 15A 125V, 2-Pole 3-Wire Grounding, 5-15R and L5-15R, Screw Terminal, Brown, 2) Feeds 2) Returns

Technical Information

Amperage
15 Amp
Applications
For Heavy Duty Applications
Base Material
Plastic,RTP
Conductor Size
14-12 AWG
Current
15 Amp
Dielectric Strength
Withstands 2,000V minimum
Face Material
RTP
Material
Thermoplastic
Mounting Type
Screw
NEMA
5-15R
Number of Poles
2 Pole
Number of Wires
3 Wire
Size
Standard
Standard
C22.2,CSA,No. 42 File 285,UL,UL498 File E2186
TC Connection
Screw Terminal
Type
Locking, Straight Blade
Voltage
125 Volt
Wattage
1875 Watt
Wire Count
3
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade

General Product Info

12-Digit UPC
783585237015
Color
Black
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
GTiN
00783585237015
Product Series
Special Combination Receptacle
Product UPC
78358523701
Weight
0.3 lb

Dimensions

Height
1.54 Inch
Length
4.16 Inch
Width
1.790 in

Certifications and Compliance

Country of Origin
USA
Features
  • Industrial
  • Combo Face Duplex Receptacle
  • 15A 125V
  • 2-Pole 3-Wire Grounding
  • Standard
