Blackburn 8H3 Split Bolt Connector

Manufacturer: Thomas & Betts / Blackburn | Catalog # 8H3 | North Coast Part # 393822
$1,622.63/c (100 ea)
ea
Order in multiples of 100 (pack qty)
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet Product Catalog Page
Type H High Strength Split-Bolt Connector made of Bronze Alloy for Use on Copper Conductors. Conductor Range for Equal Main and Tap 8 Str.-12 Sol.

Technical Information

Applications
Splicing, Tapping or Terminating Conductors in Power and Grounding Electrical Connection
Bolt Size
3/8 in
Material
Bronze
Type
H-Type, High Strength

Manufacturer Information

Brand
ABB
Sub Brand
Blackburn®

General Product Info

12-Digit UPC
783786200276
Color
Metallic
GTiN
00783786200276
Product UPC
78378620027

Dimensions

Overall Length
29/32 in
Features
  • Bolt and nut of high-strength corrosion-resistant bronze alloy. Copper pressure bar. Bolt and nut of hex design.
Standards
  • UL, CSA
Application
  • Splicing, tapping or terminating conductors in power and grounding electrical connection.
Notes
  • UL recognizes solid and stranded conductor configurations for sizes #8 and smaller and stranded configurations only for sizes #6 and larger.
  • Will accommodate 3 wires of maximum size.
  • The H3 bolts are not UL Listed or CSA Certified.
