Product image for Hubbell HBL7251C 20 Amp 120/208 VAC 4-Pole 4-Wire NEMA 18-20P Black Straight Blade Plug
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Image thumbnail 3
Email

Hubbell HBL7251C 20 Amp 120/208 VAC 4-Pole 4-Wire NEMA 18-20P Black Straight Blade Plug

Manufacturer: Hubbell / Kellems | Catalog # HBL7251C | North Coast Part # 39405
$138.89/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, Male Plug, Heavy Duty, Industrial/Commercial Grade, Angled, 4-Pole 4-Wire Non-Grounding, 20A 3 Phase 120/208V AC, 18-20P, Black, Single Pack,.

Technical Information

Amperage
20 Amp
Applications
Industrial/Commercial
Conductor Size
14-10 AWG
Cord Type
All Portable
Current
20 Amp
Grounding
Non-Grounding
Horsepower
2 hp
Material
Composite
Mounting Type
Cord
NEMA
16-20P
Number of Phases
3 Phase
Number of Poles
4 Pole
Number of Wires
4 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
NEMA® WD-6,UL,UL498 File E1706
Style
4-position Angled
TC Connection
Terminal Screws
Type
Insulgrip
Voltage
120/208 Volt
Wattage
4160 Watt
Wire Count
4
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade Devices

General Product Info

12-Digit UPC
783585013282
Color
Black
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
GTiN
00783585013282
Product Series
Heavy Duty Industrial Grade
Product UPC
78358501328
Weight
0.4 lb

Dimensions

Height
1.61 Inch
Length
3.64 Inch
Width
2.34 in

Certifications and Compliance

Country of Origin
Puerto Rico
Features
  • Industrial heavy duty plug
  • Angled, low profile
  • 4-position assembly
