3M 5730 5730 3/C LV SPLICE KIT
Product image thumbnail 0
Product image thumbnail 1
$158.29/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer 3M
Mfg Catalog # 5730
North Coast Part # 665510

Features

  • Designed for use with armor power cable
  • These kits are applicable for indoor and outdoor installations, including direct burial, aerial and submersible applications. Each kit requires at least 1 roll of 3M™ Sheath Wrap. For use with 3/C or 4/C Armor Power Cable (Teck-90) up to 1000 V. 3M™ 3/C Armored Power Cable 5730 Series accommodates a full range of cable sizes from 14 AWG–750 kcmil. The overall jacket diameter ranges from 0.62–4.00” (16–10 mm). Notes: Connectors are not included in the kit. Use only CSA certified compression connectors. Vinyl or nylon butt connectors are preferred for 5730 and 5731 series. Amount of Sheath Wrap needed is based on two half-lapped layers and 15’ rolls
  • Used for indoor and outdoor installations
  • Perfect for use in aerial, direct-burial and submersible applications
  • Rated for up to 1 kV applications
  • Includes 1 PST jacket tube, • constant force springs, • shielding tape 24 strips and 1 copper shielding sleeve
  • CSA Certified and RoHS 2011/65/EU Compliant

Legal Disclaimer

  • The designation that a product is Manufactured in the USA means the product undergoes substantial transformation in one of our U.S. Manufacturing plants. Some products contain imported components.
  • Note: 3M products offered on a government contract that require country of origin representation must be certified by 3M Trade Compliance. Contact customer service at 800-245-3573 to request a certificate.

Specifications

  • 3M ID: 80610981724
  • Brand: 3M™
  • Cable Type: Power Cable
  • Conductor Size Range: 14-10 AWG
  • Conductor Sizes: 10 AWG || 14 AWG
  • Conductor Type: Aluminum or Copper
  • Manufacturing Origin: USA
  • Number of Conductors: 3
  • Overall Jacket Diameter: 0.62 to 1.00 Inch
  • Product Type: Splice
  • Splice Type: Inline
  • Voltage: 1 kV || 600 V

Overview

UPC 05400743171
GTiN 00054007431718
Type Inline Splice
Cable Type Power Cable
Cable Size 10 AWG; 12 AWG; 14 AWG
Family Brand Name 3M
Voltage 1 kV
Conductor Size 10 AWG
Conductor Type Copper,Aluminum
