3M MU10-250DMX Male Disconnect Nn-I

$1.00/ea

Usually ships within 8 to 12 Days

Adding...

Already a Customer? Log in to view your pricing

Features

Non-insulated, butted-seam barrel with a beveled mouth offers easy insertion of wires
3M™ Scotchlok™ Standard Male Disconnect Terminal offers superior holding force while allowing for quick and easy disconnect. The terminal has a non-insulated, butted-seam barrel and withstands a maximum temperature of 347 degrees F (175 degrees C). Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.
This male disconnect terminal offers excellent holding force
Allows for quick and easy disconnect of wires
3M™ Scotchlok™ Standard Male Disconnect Terminal attaches to the mating part with a tongue that slips over the female tab. It has a non-insulated, butted-seam barrel and a beveled mouth to easily guide the wire into position. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
Mates with 0.25-in wide female tab
Accommodates wire sizes 12 to 10 AWG
Made of electrolytic copper for good conductivity and has corrosion-resistant tin plating
Withstands a maximum temperature of 347 degrees F (175 degrees C) for bare terminals
Rated 600V for building wire and 1000V for signs, fixtures or luminaires
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
50/carton, 500/case
