Hubbell Wiring Devices CSB420W 20 Amp 120/277 VAC 4-Way White Toggle Switch

Manufacturer: Hubbell / Kellems | Catalog # CSB420W | North Coast Part # 485449

$13.32/ea
ea
Adding...
Log in or register to view your price, purchase history, and more!
3 available

For Delivery

Order by Monday 4:00pm PT for delivery Tuesday
Out of stock, call for availability
Switches and Lighting Controls, Toggle Switch, Commercial Grade, Four Way, 20A 120/277V AC, Back and Side Wired, White Toggle

Technical Information

Action
Positive Snap
Actuator
Toggle
Applications
Commercial Spec Grade
Contact Configuration
Two Position
Contact Rating
Per UL 20
Current
20 A
Enclosure
None
Grade
Commercial
Material
Nylon
Number of Poles
2 Pole
Operating Cycles
50000
Operating Temperature
Maximum continuous 75C and minimum -40C without Impact
Size
4.18 in x 1.49 in x 1.83 in
Standard
UL
TC Connection
Back and Side Wired
Type
General Purpose, 2 Position, 4 Way, Standard
Voltage
120-277 Volt
Wattage
5540 Watt
Wire Size
14-10 AWG

Manufacturer Information

Family Brand Name
Hubbell Wiring Device Kellems
Sub Brand
AC Toggle Switches

General Product Info

Color
White
Environmental Conditions
Indoor Dry unless protected by additional means
GTiN
00783585154336
Product Series
General Purpose
Product UPC
78358515433
Weight
0.15 lb

Dimensions

Height
1.66 Inch
Length
4.16 Inch
Width
1.49 in

Certifications and Compliance

Country of Origin
China
