Product image for Pass & Seymour 2085-I 20 Amp 125 VAC 2-Wire NEMA 5-20R Ivory Thermoplastic Decorator Dead Front GFCI Receptacle
Image thumbnail 0
Image thumbnail 1
Email

Pass & Seymour 2085-I 20 Amp 125 VAC 2-Wire NEMA 5-20R Ivory Thermoplastic Decorator Dead Front GFCI Receptacle

Manufacturer: Legrand / Pass & Seymour | Catalog # 2085I | North Coast Part # 545109
$36.79/ea
ea
Order in multiples of 10 (pack qty)
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
From the innovator of the product category, comes a full range of Pass & Seymour GFCI receptacles to enhance safety, shorten installation times and increase productivity on the jobsite. With high-impact-resistant, thermoplastic construction, our spec-grade GFCI are the most durable GFCI available. Also features patented SafeLock™ Protection.if critical components are damaged and ground fault protection is lost, power to the receptacle is disconnected.

Technical Information

Amperage
20 Amp
Applications
For Industrial, Retail, Health Care, Office, Education, Hospitality/Lodging, Institutional, Multiple Dwelling
Conductor Size
14-10 AWG
Connection Type
Back Wire
Contact Material
Brass
Dielectric Strength
1500 V
Grade
Specification
Material
Nylon
Mounting Type
Wallplate
NEMA
5-20R
Number of Poles
2 Pole
Number of Wires
3 Wire
Style
Decorator
Temperature Rating
-35 degrees C to 66 degrees C
Type
Dead-Front, Decorator, Blank Face
Voltage
125 Volt

Manufacturer Information

Brand
Pass & Seymour

General Product Info

12-Digit UPC
785007423402
Color
Ivory
Environmental Conditions
UL 94 Requirements, V2 Rated Flammability
GTiN
00785007423402
Product UPC
78500742340

Dimensions

Depth
0.98 Inch
Height
4.2 Inch
Length
4.2 Inch
Width
1.72 in
Features & Benefits
  • Mounting screws are shipped captive in the device and wall plate for easier installation.
  • 1/4\" thinner than competitors' GFCIs; leaves more room for wires in the box.
  • Side or internal screw-pressure-plate back wire with #10 #14 AWG solid or stranded copper wire. Two back wire holes per terminal. GFCIs with Auto-Ground assure a positive ground to metal box.
  • For covering patents, see www.legrand.us/patents.
  • Ground screw has a back wire clamp for easy installation.
  • Extra-long strap. Button colors match the device face. Dual-direction test and reset buttons. Class A rated GFCI. Supplied with matching TP26 nylon wall plate. Tri-drive screws.
  • Exceeds UL943 voltage surge requirements; survives 100x the required UL 3kA/6kV voltage surge test cycles. FSUL Listed (Federal Specification WC596). Trip indicator light (red LED).
  • 10kA short circuit rating.
Available Options
  • Spec Grade Dead Front 20A GFCI, Black
  • Spec Grade Dead Front 20A GFCI, Ivory
  • Spec Grade Dead Front 20A GFCI, White
  • Spec Grade Dead Front 20A GFCI, Light Almond
