Product image for Hoffman E4SPBY25 Extra-Large Pushbutton Enclosures, Type 12, 4PB x 30.5mm, Gray, Steel
Email

Hoffman E4SPBY25 Extra-Large Pushbutton Enclosures, Type 12, 4PB x 30.5mm, Gray, Steel

Manufacturer: nVent Hoffman | Catalog # E4SPBY25 | North Coast Part # 589746
$355.48/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
Extra-Large Pushbutton Enclosures with Panels are designed to hold 30.5-mm and 22.5-mm pushbuttons and switches, with 2.50-in. (64-mm) center-to-center of pushbutton holes.

Technical Information

Applications
For Push Buttons and Switches
Color Coding
ANSI 61
Material
Steel
Number of Holes
4 Hole
Size
4PB x 30.5mm
Standard
CSA File Number 42186: Type 12,CUL Listed Per CSA C22.2 No. 94; Type 12, 13; File No. E61997,IEC 60529, IP65,NEMA/EEMAC Type 12, 13,UL 508A Listed; Type 12, 13; File No. E61997
Type
4-Hole, Extra-Large

Manufacturer Information

Brand
nVent Hoffman
Sub Brand
Hoffman

General Product Info

12-Digit UPC
783510588700
Color
Gray
Finish
Powder Coated
GTiN
00783510588700
Product UPC
78351058870
Used With
30.5 mm Push Button
Weight
9.02 lb

Dimensions

Depth
6.8 Inch
Height
8-1/2 Inch
Hole Size
30.5 mm
Length
10 Inch
Thickness
1.9 mm
Width
7.5 in
Features
  • Seams continuously welded and ground smooth
  • Captivated cover screws thread into sealed wells
  • Continuous hinge
  • Factory stamped 4-way pushbutton holes
  • Oil-resistant gasket
  • Removable 14 gauge panel included, supported by weldnuts
  • Bonding provision on cover
  • External welded-on mounting brackets for easy installation
  • 30.5-mm or 22.5-mm size holes
