Ocal LBD2200-G 3/4" PVC-Coated Ferrous Iron Rigid 90° Pulling Elbow - Gray

Manufacturer: Thomas & Betts / Ocal | Catalog # LBD2200-G | North Coast Part # 643186
$381.00/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet Brochure Product Catalog Page
PVC Coated Pulling Elbow, 90 Degree Bend, With Pressure-Sealing Sleeves Seal Connections, Pipe Size 3/4 Inch/21 Metric, Gray Iron, Dark Gray

Technical Information

Applications
Used in Rigid Conduit to Act as Pull Outlets for Conductors
Material
Iron
Size
3 in
TC Connection
90 Degree Bend
Trade Size
3/4 Inch; 21 mm
Type
90

Manufacturer Information

Brand
ABB

General Product Info

12-Digit UPC
704508391324
Color
Gray
Finish
PVC Coated
GTiN
00704508391324
Product UPC
70450839132
Features
  • Cover openings on an angle, permitting conductors to be pulled straight through hubs from either direction
  • Taper threaded hubs with integral bushings
  • Pressure-sealing sleeves seal connections
  • Coated with a nominal .002 in. (2 mil) blue urethane on both interior and exterior
  • Domed cover permits easy conductor bends, relieves strain on insulation
  • Shipped complete with elbow, cover and cover screws.
  • Nominal .040 in. (40 mil) PVC coating bonded to exterior
Application
  • Make 90 degree bends in conduit system, allowing straight pull in either direction
  • Provide for conductor entrance to motors
  • Act as pull outlets especially for conductors that are stiff due to large size or type of insulation
  • Provide for conduit service entrance to buildings
  • Provide access to wiring for maintenance and future system changes
Notes
  • Ratings are prior to PVC coating
  • Metric size designator (ANSI C80.1-1994)
  • Dimensional values are prior to PVC coating
