Thomas & Betts 210214S 14 to 10 AWG 0.63 x 0.38 x 0.17 Inch Tiined Copper Insulation Splice

Manufacturer: Thomas & Betts | Catalog # 210214S | North Coast Part # 67195
$305.64/c (100 ea)
ea
Order in multiples of 250 (pack qty)
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
Insulation Piercing Magnet Wire Splice, Length .63 Inches, Width .38 Inches, Height .37 Inches, Wire Range #14 AWG - #10 AWG 4,110 Circular Mil Area - 20,760 Circular Mil Area, Copper Alloy, Tin Plated

Technical Information

Applications
For Aluminum to Copper, Aluminum to Aluminum or Copper to Copper Magnet Wire Connections
Conductor Size
14-10 AWG
Contact Material
Copper
Material
Copper
Standard
UL E9809
Type
Insulation Piercing, Short Sleeve

Manufacturer Information

Brand
ABB
Sub Brand
Dragon Tooth®

General Product Info

12-Digit UPC
786210867687
Finish
Tin Plated
GTiN
05414363077091
Product UPC
78621086768
Features
  • Designed to penetrate magnet wire insulation during application, eliminating the need for stripping, brazing, welding or other methods of joining magnet wire.
Application
  • For aluminum to copper, aluminum to aluminum or copper to copper magnet wire connections.
Notes
  • Wire sizes and combinations shown have been tested to and meet or exceed Thomas & Betts specifications. Connectors may be suitable for other wire sizes or combinations. Thomas & Betts sells these connectors with the understanding that the user will perform necessary tests to determine their suitability for the intended purpose.
