BUR YA38L2NNTFX CU HYLUG-500FLEX-NA

Manufacturer: Burndy | Catalog # YA38L2NNTFX | North Coast Part # 757798
$65.71/ea
ea
Adding...
Log in or register to view your price, purchase history, and more!
12 available

For Delivery

Order by Friday 4:00pm PT for delivery Monday
Out of stock, call for availability
Specification Sheet
500 kcmil H,I,K / 550 kcmil G,H,I,535 DLO CU, Two Hole, 1/2 Stud Size, 1-3/4 Hole Spacing, Standard Barrel, Inspection Window, Narrow Tongue, Internal Chamfer, Tin Plated, UL/CSA, 90C, Up to 35kV, Pink Color Code, L99 Die Index.

Technical Information

Applications
For Flex Conductor
Color Coding
Pink
Connection Type
Terminal
Material
Copper
Max Voltage
35000 V
Number of Holes
2 Hole
Plated?
Yes
Plating Type
Tin - Electro Plated
Type
YAV-L-NTFX

Manufacturer Information

Family Brand Name
Burndy
Sub Brand
Terminals, HYLUG

General Product Info

Color
Pink
GTiN
00781810034743
Product UPC
78181003474

Dimensions

Height
1-1/4 Inch
Length
5.35 in
Overall Length
5.35 in
Width
1.63 in

Certifications and Compliance

Country of Origin
USA
CSA
Yes
