Product image for Burndy YAV27TC12FXB 3/0 Flex G,H,I,K,M,DLO, 3/0 AWG CU, One Hole, 1/2 Stud Size, Long Barrel, Bell End, Tin Plated, UL/CSA, 90.C, Up to 35kV, Orange Color Code, 14 Die Index
Email

Burndy YAV27TC12FXB 3/0 Flex G,H,I,K,M,DLO, 3/0 AWG CU, One Hole, 1/2 Stud Size, Long Barrel, Bell End, Tin Plated, UL/CSA, 90.C, Up to 35kV, Orange Color Code, 14 Die Index

Manufacturer: Burndy | Catalog # YAV27TC12FXB | North Coast Part # 9379
$36.76/ea
ea
Log in or register to view your price, purchase history, and more!
Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
Copper Compression Lug, 1 Hole w/o Inspection Window, 3/0 Flex, 1/2" Stud, Long Barrel, Belled End, Tin Plated.

Technical Information

Applications
For Flex Conductors
Cable Size
3/0 AWG, 3/0 AWG Weld, 450/24, 95 SQ-MM For Class 5 Conductor
Color Coding
Orange
Conductor Material
Copper
Conductor Size
3/0 AWG
Connection Type
Terminal
Material
Copper
Max Voltage
35000 V
Number of Holes
1 Hole
Plated?
Yes
Plating Type
Tin - Electro Plated
Stud Size
0.5 in
Type
Long Barrel, Tin Plated
Voltage
35,000 Volt

Manufacturer Information

Brand
Burndy
Sub Brand
HYLUG

General Product Info

12-Digit UPC
781810080825
Finish
Tin Plated
GTiN
00781810080825
Product UPC
78181008082

Dimensions

Height
0.82 Inch
Hole Size
14 mm
Length
3.44 Inch
Overall Length
3.44 in
Width
1.04 in

Certifications and Compliance

Country of Origin
USA
CSA
Yes
  • UL Listed 90 DEG C, 600 V - 35 KV, 45 DEG And 90 DEG Angles Are Available, Finish: Electro-Tin Plated, Tongue Angle: Straight, Wire Strip Length: 1-13/16 IN, Temperature Rating: 90 DEG C, Die Index: 14, Tools, Die Set Catalog Number, And (number Of Crimps): Mechanical: MD6, OUR840, MD7-34R Tool, W27VT Die, (4), Hydraulic: BCT500HS, Y500CTHS Tool, W27VT Die, (4), Y35, Y39, Y750, PAT750 Tool, U27RT Die, (2), Y46 Tool, U27RT Die With PUADP-1 Adapter, (2), Color Code: Orange, Dieless Tools (number Of Crimps): Y644HS Tool, (1), Y81KFT, Y81KFTMBH, PAT81KFT-18V, MY29-11 Tool, (2), Conductor Type: Commercial Stranded Copper, Flexible Copper
