Product image for Thomas & Betts RB1157 #10 Bolt Hole 18-14 AWG Wire Range Blue Insulated Vinyl Fork Terminal
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Image thumbnail 3
Image thumbnail 4
Email

Thomas & Betts RB1157 #10 Bolt Hole 18-14 AWG Wire Range Blue Insulated Vinyl Fork Terminal

Manufacturer: Thomas & Betts | Catalog # RB1157 | North Coast Part # 95339
$71.30/c (100 ea)
Order in multiples of 1000 (pack qty)
Log in or register to view your price, purchase history, and more!
800 available

For Pick Up

at Auburn Opens Thursday 4:00am PT
800 available

For Delivery

Order by 4:00pm PT for delivery tomorrow
Not in local stock *
Check another branch
Specification Sheet Brochure Product Catalog Page
Vinyl-Insulated Fork Terminal, Length .97 Inches, Width .31 Inches, Maximum Insulation .170, Bolt Hole #10, Wire Range #18-#14 AWG, Color Blue, Copper, Tin Plated, 1,000 Pack

Technical Information

Barrel Type
Brazed Seam
Conductor Size
18-14 AWG
Insulation Material
Vinyl
Insulation Type
Insulated Vinyl
Material
Copper
Standard
UL E9809
Stud Size
#10
Temperature Rating
105 degrees C
Type
Short Sleeve
Voltage
600 Volt
Wire Size
18-14 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Sta-Kon®

General Product Info

12-Digit UPC
786210819112
Color
Blue
Finish
Electro Tin Plated
GTiN
05414363933977
Product UPC
78621081911
Features
  • These fork terminals have extra-long PVC insulation sleeve for protection and stress relief at wire's flex point. Brazed seam barrel is serrated for high pull-out value. Insulation is color-coded.
Notes
  • Most terminals can be put on Mylar Tape for reel fed applications by adding the suffix M to the bulk catalog numbers.
