Thomas & Betts B14-14 18 to 14 AWG 1/4 Inch Stud Metallic Electrotinned Copper Non-Insulated Ring Terminal

Manufacturer: Thomas & Betts | Catalog # RB14-14 | North Coast Part # 97150
$265.62/c (100 ea)
ea
Order in multiples of 100 (pack qty)
Log in or register to view your price, purchase history, and more!
0

Not Available for Pickup at Auburn Opens Thursday 4:00am PT
0 available

For Delivery

Not in local stock *
Check another branch
*Next Day Delivery not avail / contact sales for lead times & return policy
Specification Sheet
Non-Insulated Ring Terminal, Length .93 Inches, Width .50 Inches, Bolt Hole 1/4 Inch, Wire Range #18-#14 AWG, Copper, Tin Plated

Technical Information

Conductor Size
18-14 AWG
Flamability Class
Rated V-2 Per UL94
Insulation Material
Nylon
Insulation Type
Insulated Nylon
Material
Copper
Stud Size
1/4 in
Temperature Rating
105 degrees C
Terminal Type
RB
Type
Long Sleeve
Voltage
600 Volt
Wire Size
18-14 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Sta-Kon®

General Product Info

12-Digit UPC
786210804170
Color
Blue
Finish
Tin Plated
GTiN
05414363077435
Product UPC
78621080417
Used With
Round Conductors

Dimensions

Height
3 Inch
Thickness
.03 in
Width
1.3 in
Features
  • Self-insulated with high dieletric-strength nylon sleeves. An inner bronze insulation grip sleeve lengthens the flexing radius of the conductor and eliminates conductor creep.
Certifications
  • CSA
  • UL
