Red Dot 2IH4-2 2-Gang Weatherproof Metallic Device Box, (4) 3/4" Hubs, 2" Deep

Manufacturer: Thomas & Betts / Red Dot | Catalog # 2IH4-2 | North Coast Part # 97163
$4,070.46/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
16 available

For Pick Up

at Auburn Closes 3:00pm PT
16 available

For Delivery

Order by 4:00pm PT for delivery tomorrow
Not in local stock *
Check another branch
Specification Sheet
Two Gang Universal Weatherproof Box, 31 Cubic Inches, Hub Size 3/4 Inch, Silver, Aluminum, 4 Outlets with 2 on Top and 1 on Bottom and Back

Technical Information

Applications
Dry-Tite Boxes and Covers Protect Wiring Devices, Switches, Electronic Components and Terminal Blocks in Dry, Damp and Wet Locations
Cable Entry
3/4 in Hub
Material
Aluminum
Mounting Type
Screw
Number of Gangs
2 Gang
Type
Universal, 4-Outlet, Rectangular, Raintight

Manufacturer Information

Brand
ABB
Sub Brand
Red Dot®

General Product Info

12-Digit UPC
042269394308
Color
Silver
Finish
Powder Coated
GTiN
05414363936374
Product UPC
04226939430

Dimensions

Depth
52.3748 mm
Height
5.4 Inch
Length
115.87 mm
Width
117.475 mm
Features
  • Clean cover edges provide good gasket sealing.
  • Convenient mounting lugs for a variety of mounting methods
  • Die Cast construction and industrial design combine to produce a rugged protective enclosure for devices.
  • Precision cast and machined surfaces permit safer wire pulling.
  • Securely fastened mounting plates reduce costly call backs
  • Alloy A380 aluminum, certified zinc alloy and stainless steel springs provide increased corrosion resistance
  • Clear UL and cubic content markings speed approval by inspectors
Certifications
  • UL
Application
  • Junction box for branch conduits
  • Dry-tite boxes and covers protect wiring devices, switches, electronic components and terminal blocks in dry, damp and wet locations
  • Accessible wiring chamber provides a convenient location to maintain or change a system, pull conductors and make splices
Notes
  • Rain tight when used with appropriate Red Dot covers.
