ABB S202MUC-K6 MCB S200MUC 2P K 6A
$163.24/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer ABBEMPLV
Mfg Catalog # S202MUC-K6
North Coast Part # 1354130

Specifications

North American Specifications (UNSPSC)

  • UNSPSC: 39121603 Miniature circuit breakers
  • IGCC: 4897 Miniature circuit breakers
  • Brand Name: ABB
  • Type: High Performance MCB Provides Compact Supplementary, Energy Limiting, Circuit Protection
  • Special Features: Equipped with Permanent Magnets that Assist in the Forced Extinguishing of the Arc.
  • Application: Supplementary Protective Devices. Protection and Control of the Circuits Like Motors, Transformers and Auxiliary Circuits, Against Overloads and Short-Circuits.
  • Standard: UL 1077, CSA 22.2 No. 235
  • Voltage Rating: 277/Y480 VAC, 250/500 VDC
  • Amperage Rating: 6 Amps
  • Trip Type: K
  • Interrupt Rating: 10 kA
  • Number Of Poles: 2
  • Auxiliary Contacts: Yes
  • Length: 69 mm
  • Width: 35 mm
  • Height: 88 mm
  • Operating Temperature: -25 to +55 Degrees Celcius

Packaging

  • Outer Quantity: 5
  • Outer Dimensions (inches): 3.15x7.2x4.13
  • Weight Uom: 0.48 lbs. Each

Overview

GTiN 00888614260689
Length 69 mm
Width 35 mm
Operating Temperature -25 To 55 C
Voltage 277/480 Volt
Type High Performance MCB Provides Compact Supplementary, Energy Limiting, Circuit Protection
Applications Supplementary Protective Devices. Protection and Control of the Circuits Like Motors, Transformers and Auxiliary Circuits, Against Overloads and Short-Circuits.
Height 88 mm
Family Brand Name Thomas & Betts
Box Quantity 5
Amperage 6 Amp
Trip Type K
Number of Poles 2
Interrupt Rating 10 kA
