ABB S203MUC-K6 MCB S200MUC 3P K 6A
$244.90/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer ABBEMPLV
Mfg Catalog # S203MUC-K6
North Coast Part # 1354131

Specifications

North American Specifications (UNSPSC)

  • UNSPSC: 39121603 Miniature circuit breakers
  • IGCC: 4897 Miniature circuit breakers
  • Brand Name: ABB
  • Type: High Performance MCB Provides Compact Supplementary, Energy Limiting, Circuit Protection
  • Special Features: Equipped with Permanent Magnets that Assist in the Forced Extinguishing of the Arc.
  • Application: Supplementary Protective Devices. Protection and Control of the Circuits Like Motors, Transformers and Auxiliary Circuits, Against Overloads and Short-Circuits.
  • Standard: UL 1077, CSA 22.2 No. 235
  • Voltage Rating: 277/Y480 VAC
  • Amperage Rating: 6 Amps
  • Trip Type: K
  • Interrupt Rating: 10 kA
  • Number Of Poles: 3
  • Auxiliary Contacts: Yes
  • Length: 69 mm
  • Width: 52.5 mm
  • Height: 88 mm
  • Operating Temperature: -25 to +55 Degrees Celcius

Packaging

  • Inner Quantity: 1
  • Inner Dimensions (inches): 3.15x2.16x4.13
  • Outer Quantity: 3
  • Outer Dimensions (inches): 3.15x6.48x4.13
  • Weight Uom: 1.68 lbs. Each

Overview

GTiN 00888614274358
Length 69 mm
Width 52.5 mm
Operating Temperature -25 to +55 C
Voltage 277/480 Volt
Type High Performance MCB Provides Compact Supplementary, Energy Limiting, Circuit Protection
Applications Supplementary Protective Devices. Protection and Control of the Circuits Like Motors, Transformers and Auxiliary Circuits, Against Overloads and Short-Circuits.
Height 3.4646 in
Family Brand Name Thomas & Betts
Carton Qty 1
Box Quantity 3
Amperage 6 Amp
Trip Type K
Number of Poles 3 Pole
Interrupt Rating 10 kA
