ABB S203U-K30 MCB 3P K 30A 240 BCPD
$176.38/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer ABB
Mfg Catalog # S203U-K30
North Coast Part # 936045

Specifications

North American Specifications (UNSPSC)

  • UNSPSC: 39121603 Miniature circuit breakers
  • IGCC: 4897 Miniature circuit breakers
  • Brand Name: ABB
  • Type: High Performance MCB, Branch Circuit Protection
  • Special Features: DIN Rail Mounting, Finger Safe and Multi-Function Terminals
  • Application: Designed for Allowing Higher In-Rush Current During System Start Up; Example: Motors, Transformers
  • Standard: UL 489, CSA 22.2 No. 5, UL E212323
  • Voltage Rating: 240 VAC
  • Amperage Rating: 30 Amps
  • Frequency Rating: 50/60 Hertz
  • Trip Type: K
  • Interrupt Rating: 10 kA
  • Number Of Poles: 3
  • Auxiliary Contacts: Yes
  • Length: 71 mm
  • Width: 52.5 mm
  • Height: 92 mm
  • Operating Temperature: -25 to +55 Degrees Celcius

Packaging

  • Inner Quantity: 1
  • Outer Quantity: 3
  • Outer Dimensions (inches): 7.2x4.13x3.15
  • Weight Uom: 92.5 lbs. per 100

Overview

UPC 66201916767
GTiN 00662019167671
Length 71 mm
Width 52.5 mm
Operating Temperature -25 to +55 C
Voltage 240 Volt
Type High Performance MCB, Branch Circuit Protection
Applications Designed for Allowing Higher In-Rush Current During System Start Up; Example: Motors, Transformers
Height 3.6221 in
Frequency 50/60 Hz
Family Brand Name Thomas & Betts
Carton Qty 1
Box Quantity 3
Amperage 30 Amp
Trip Type K
Number of Poles 3 Pole
Interrupt Rating 10 kA
