Allied Moulded Products 9375-FR 3-3/4 x 4 Inch 14 In Polycarbonate Round Ceiling Fan/Fixture Outlet Box
Product image thumbnail 0
Product image thumbnail 1
$560.60/c (100 ea)
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allied Molded Products
Mfg Catalog # 9375-FR
North Coast Part # 664139

Features

1/2" deep base with side cube wiring capacity, fan/fixture screws for joist mounting

Specifications

  • Catalog #: 9375-FR
  • Width: 4 in.
  • Depth: 3-13/16 in.
  • Volume: 14 cu. in.
  • Round Ceiling Box
  • Carton Quantity: 24
  • Carton Weight: 7 lb.
  • UPC: 085339792918
  • UNSPSC: 39121316
  • Patents: U.S. Patent No. 6,365,831 B1
  • Country of Origin: United States of America
  • Color: Black
  • Material: Polycarbonate
  • Mounting: Bottom mount
  • Additional Materials: Plated carbon steel fasteners
  • Support Rating: 110 lbs fixture support and 70 lbs fan support

Application

New and old work residential construction 2 HR fire resistive walls and ceilings (70 lbs. fan support and 110 lbs. fixture support)

Standards

ANSI / UL 514C: File No. E30594

Fire Classification

Fire Test of Building Construction Materials

  • ANSI / UL 263: File No. CEYY.R9379 (Category / File No.)
  • Note: Products must also be certified to: ANSI / UL 514C

Fire Resistance Classification in Wall Assemblies 2-Hours or less

  • Shall be separated by a horizontal distance of not less than 3 inches

Fire Resistance Classification in Floor-Ceiling Assemblies 2-Hours or Less

  • Note: For more details please refer to the UL fire resistive directory and Allied Moulded’s CEYY.9379 (Outlet boxes and fittings classified for fire resistance)
  • Distance between boxes in adjacent cavities may be reduced to 5 ½ inches

Overview

UPC 08533979291
GTiN 00085339792918
Width 4 in
Size Depth=3 13/16", Dia=4"
Color Black
Type 4" Dia. Round Fan Support Box For Use With Nonmetallic Sheathed Cable
Insulation Type Nonconductive Nonmetallic
Material Polycarbonate - Thermoplastic Box
Applications New and old work residential construction 2 HR fire resistive walls and ceilings (70 lbs. fan support and 110 lbs. fixture support)
Mounting Type Bottom Mount
Depth 3 in
Standard UL 514 C
Family Brand Name Allied Moulded
Construction Injection Molded
Carton Qty 24
Cable Entry Speed Klamps
