Allied Moulded Products P-352OW 3-25/64 x 5-59/64 x 3-11/16 Inch 52 In 3-Gang Galvanized Steel Switch/Receptacle Outlet Box
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$1,004.17/c (100 ea)
In Stock | 68 available at 9 locations
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allied Molded Products
Mfg Catalog # P-352OW
North Coast Part # 339981

Features

Molded-in spline device holes, slot provision for low voltage divider, rectangular exterior for easy cut-in

Specifications

  • Brand: flexBOX
  • Catalog #: P-352OW
  • Height: 3-11/16 in.
  • Width: 5-15/16 in.
  • Depth: 3-3/8 in.
  • Volume: 55 cu. in.
  • Type of Installation: Old Work
  • Wall Box
  • Number of Gangs: 3
  • Carton Quantity: 12
  • Carton Weight: 6 lb.
  • UPC: 085339332015
  • UNSPSC: 39121308
  • Patents: U.S. Patent No. 6,365,831 B1
  • Country of Origin: United States of America
  • Color: Black
  • Material: Polycarbonate
  • Mounting: Metal wing brackets/nonmetal ears wall compression
  • Additional Materials: Galvanized steel brackets and plated carbon steel fasteners

Application

Old work residential construction 2 HR fire resistive walls

Standards

ANSI / UL 514C: File No. E30594

Fire Classification

Fire Test of Building Construction Materials

  • ANSI / UL 263: File No. CEYY.R9379 (Category / File No.)
  • Note: Products must also be certified to: ANSI / UL 514C

Fire Resistance Classification in Wall Assemblies 2-Hours or less

  • Note: For more details please refer to the UL fire resistive directory and Allied Moulded’s CEYY.9379 (Outlet boxes and fittings classified for fire resistance)
  • Shall be separated by a horizontal distance of not less than 24 inches

Overview

UPC 08533933201
Item Long Description 55.0 Cu. In. Three gang electrical box for use with nonmeatllic sheathed cable - Molded-in spline device holes, slot provision for low voltage divider, rectangular exterior for easy cut-in - Old work residential construction 2 HR fire resistive walls - Polycarbonate - Thermoplastic - Size: D=3 3/8", W=5 15/16", H=3 11/16" - Mount with Metal wing brackets/nonmetal ears wall compression
GTiN 00085339332015
Width 5-15/16 in
Size D=3 3/8", W=5 15/16", H=3 11/16"
Color Black
Type Three Gang Electrical Box For Use With Nonmetallic Sheathed Cable
Insulation Type Non-Conductive,Non-Metallic
Material Polycarbonate - Thermoplastic
Applications Old work residential construction 2 HR fire resistive walls
Mounting Type Metal Wing Brackets/nonmetal Ears Wall Compression
Depth 3 in
Height 3 in
Family Brand Name Allied Moulded
Construction Injection Molded
Number of Gangs 3 Gang
Cable Entry Twelve Molded-in Speed Klamps With Two 1/2" Knockout
Sub Brand FLEXBOX
