BRADY DAT-51-619-10 Label,Dot Mtx,B
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Usually ships within 6 to 8 Days
Already a Customer? Log in to view your pricing
Manufacturer Brady
Mfg Catalog # DAT-51-619-10
North Coast Part # 18491


  • Leaves no adhesive residue when removed, so it's ideal for permanent or temporary applications
  • Matte finish material with permanent acrylic adhesive can be thermal transfer printed or dot matrix printed
  • UL approved;CSA accepted
  • Good smudge and solvent resistance in temperatures of -94 to 293° F (-70 to 145° C)


  • Applications: Circuit Board Labeling; Component and Equipment Labeling
  • Board Application: Through Hole - Top
  • Brand Name: Brady®
  • Bulk Part: Not a Bulk Part
  • Color: White
  • Compatible Surface Types: High Surface Energy
  • Corner Type: Rounded Corners
  • Enables Industry Compliance: ASTM B 117; ASTM D 1000; ASTM D 2979; ASTM G 155; CSA Approved; UL Recognized
  • Finish: Matte
  • For Use with Printer: Dot Matrix Printers
  • Label/Media Format: Pack
  • Primary Noun, Basic Function: Label
  • Print Technology: Dot Matrix
  • Printer and Label Applications: Circuit Board; General Identification; Rating & Name Plates
  • Printer Compatibility: Dot Matrix
  • Quantity per Roll: 10000
  • Quantity per Row: 7
  • Ribbon Series: R2000; R5000
  • Shape: Rectangle
  • Suggested Ribbon Series: R5000
  • Total Qty per Pack: 10000 Label(s) / Pack
  • Total Quantity: 10000
  • Trade Name: DATAB®
  • Adhesive Type: Permanent Acrylic
  • After Process: Yes, this material will work with this application
  • Brady Material Number: B-619
  • Label Properties: Heat Resistant Labels; Permanent Adhesive Labels
  • Material: Polyester
  • Resistance Properties: Abrasion-Resistant; Corrosion-Resistant; Humidity-Resistant; Smear-Resistant; UV-Resistant; Weather-Resistant
  • SAP B-Number: B-619
  • Dimensions: 0.375 in H x 1 in W
  • Dimensions (Metric): 25.40 mm W x 9.53 mm H
  • Dimensions 2: 0.375 in H x 1 in W
  • Height (in/ft/yd): 0.375 in
  • Height (mm/cm/m): 9.53 mm
  • Horizontal Repeat (mm): 27.94 mm
  • Label/Tape Size (in/ft/yd): 0.375 in H x 1 in W
  • Maximum Service Temperature °C: 145 °C
  • Maximum Service Temperature °F: 293 °F
  • Minimum Application Temperature °C: 10 °C
  • Minimum Application Temperature °F: 50 °F
  • Minimum Service Temperature °C: -70 °C
  • Minimum Service Temperature °F: -94 °F
  • Printable Area Dimensions (Metric): 9.53 mm H x 25.40 mm W
  • Printable Area Height (mm/cm/m): 9.53 mm
  • Printable Area Width (mm/cm/m): 25.40 mm
  • Sign Size-General: 0.375 in x 1 in
  • Size - Width (mm): 25.40 mm
  • Thickness (in/ft/yd): 0.0036 in
  • Thickness (mm/cm/m): 0.091 mm
  • Vertical Repeat: 0.5 in
  • Vertical Repeat (mm): 12.70 mm
  • Web Width (mm/cm/m): 218.44 mm
  • Width (in/ft/yd): 1 in
  • Width (mm/cm/m): 25.4 mm

Regulatory Information

  • Contains CA PROP 65 Substance: Yes Contains-Label not req.
  • Contains CA PROP 65 Substance: No
  • Contains Heavy Metal(s): Unavailable
  • DOT Regulated Product: No = not regulated by DOT
  • EU RoHS Compliance: Pass 2011/65/EU(Pass 2015/863)
  • EU RoHS Compliant: Yes
  • SDS Safety Data Sheet required: No = MSDS/SDS is not required


UPC 66282028915
Item Long Description Permanent Polyester (B-619) is suitable for marking components in control panels, electronic components and circuit boards, faceplates and electrical receptacles.
GTiN 00662820289159
Finish Matte
Width 1 in
Adhesive Type Permanent Acrylic
Color White
Type Label
Thickness 0.003 in
Material Polyester
Applications Circuit Board ID - After Process; Circuit Board ID - Through Hole Top; Component & Equipment ID
Height 0.375 in
Shape Rectangle
Family Brand Name Brady
Qty per Row 7
Max Operating Temperature 293 degrees F
Min Operating Temperature -94 degrees F
Sub Brand DATAB Markers
CA Prop65 Warning No - Does Not Contain
Max Temperature 293 degrees F
Min Temperature -94 degrees F
