BRADY HSNX-800-2-WT 2.200 X 0.800 I
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Usually ships within 6 to 8 Days
Already a Customer? Log in to view your pricing
Manufacturer Brady
Mfg Catalog # HSNX-800-2-WT
North Coast Part # 427685


  • Dot matrix or thermal transfer printable tags are available in white, yellow or green
  • B-508 tags have excellent tear, solvent and heat resistance properties
  • Service temperature of -94°F to 266°F (-70°C to 130°C)


  • Applications: Wire and Cable Labeling
  • Brand Name: Brady®
  • Color: White
  • Diagram: Icon 39 (downwards triangle with centre dot)
  • Enables Industry Compliance: ASTM D 1000; ASTM E 162; ASTM E 595; ASTM E 662
  • Finish: Matte
  • Flame Retardant: Yes
  • For Use with Printer: BradyPrinter i7100; BRADYPRINTER PR Plus Series Label Printer; THT 3" Core Printer
  • Primary Noun, Basic Function: Tag
  • Printer Compatibility: BBP12; BBP11; BP1244; BP1344; BP2461; BP3481; BP6441; MVP200; MVP300; 300XPlusII; 360XPlusII; 600XPlusII; PR200Plus; PR300Plus; PR600Plus; IP300; IP600
  • Printer Compatibility (Print): BBP12
  • Quantity per Roll: 2500
  • Quantity per Row: 1
  • Recommended Ribbon: R4300
  • Ribbon Series: R4300; R7950
  • Shape: Rectangle
  • Suggested Ribbon Series: R4300; R5000
  • Total Qty per Pack: 2500 Tag / Roll
  • Total Quantity: 2500
  • Trade Name: Nomex®
  • Brady Material Number: B-508
  • Material: Nomex® Tag
  • Material Properties: Rigid
  • Resistance Properties: Chemical-Resistant; Corrosion-Resistant; Heat-Resistant; Humidity-Resistant; Tear-Resistant; UV-Resistant; Weather-Resistant
  • SAP B-Number: B-508
  • Dimensions: 0.8 in H x 2.2 in W
  • Dimensions (Metric): 55.88 mm W x 20.32 mm H
  • Dimensions 2: 0.8 in H x 2.2 in W
  • Height (in/ft/yd): 0.8 in
  • Height (mm/cm/m): 20.32 mm
  • Maximum Service Temperature °C: 130 °C
  • Maximum Service Temperature °F: 266 °F
  • Minimum Service Temperature °C: -70 °C
  • Minimum Service Temperature °F: -94 °F
  • Roll/Tape Size (in/ft/yd): 0.8 in H x 2.2 in W
  • Sign Size-General: 0.8 in x 2.2 in
  • Size - Width (mm): 55.88 mm
  • Thickness (in/ft/yd): 0.012 in
  • Thickness (mm/cm/m): 0.305 mm
  • Vertical Repeat (mm): 25.70 mm
  • Web Width (in/ft/yd): 3.25 in
  • Web Width (mm/cm/m): 82.55 mm
  • Width (in/ft/yd): 2.2 in
  • Width (mm/cm/m): 55.88 mm

Regulatory Information

  • Contains CA PROP 65 Substance: Yes Contains-Label not req.
  • Contains CA PROP 65 Substance: No
  • Contains Heavy Metal(s): No - Does not contain
  • DOT Regulated Product: No = not regulated by DOT
  • EU RoHS Compliance: Pass 2011/65/EU(Pass 2015/863)
  • EU RoHS Compliant: Yes
  • SDS Safety Data Sheet required: No = MSDS/SDS is not required


UPC 66282057750
Item Long Description B-508 tags are designed as high performance bundle and cable identification tags to stand up to the harshest environments.
GTiN 00662820577508
Finish Matte
Width 2.2 in
Color White
Type Tag
Thickness 0.012 in
Material B-508 Nomex
Applications Cable & Wire Marking
Height 0.8 in
Shape Rectangle
Family Brand Name Brady
Max Operating Temperature 266 degrees F
Min Operating Temperature -94 degrees F
Sub Brand Nomex
CA Prop65 Warning No - Does Not Contain
Max Temperature 266 degrees F
Min Temperature -94 degrees F
