BRADY M21-750-488 Label,BMP21,B488,
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$29.69/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Brady
Mfg Catalog # M21-750-488
North Coast Part # 886001

Features

  • Matte white polyester material has a permanent acrylic adhesive and is thermal transfer printable
  • Ideal for general and bar code labeling on flat, smooth surfaces
  • UL approved;CSA accepted
  • All-in-one cartridge includes ribbon and label supply

Specifications

  • Applications: Barcode Labeling; Circuit Board Labeling; Data and Telecommunications Labeling; Electrical Labeling; General Identification; Laboratory Labeling
  • Brand Name: Brady®
  • Color: Black on White
  • Compatible Surface Types: High Surface Energy
  • Diagram: Icon 5 (circle with centre dot)
  • Enables Industry Compliance: ANSI/ESD S541-2008; ASTM B 117; ASTM D 1000; ASTM D 2979; ASTM G 155; CSA Approved; UL Recognized
  • Finish: Matte
  • For Use with Printer: BMP®21 LAB Label Printer; BMP®21 Labeler; BMP®21 PLUS Portable Label Printer; IDPAL™ Handheld Label Maker; LABPAL™ Handheld Label Maker
  • Label/Media Format: Label/Media in Cartridge with Ribbon
  • Manufacturer Part Number: M21-750-488
  • Primary Noun, Basic Function: Label
  • Print Technology: Thermal Transfer
  • Printer and Label Applications: General Identification; Laboratory
  • Printer Compatibility: BMP21-PLUS; BMP21-LAB; BMP21; IDPAL; LABPAL
  • Printer Compatibility (Print): BMP21-PLUS; BMP21-LAB
  • PSPA Photoluminescence Class: Not Rated
  • Quantity per Row: 1
  • Reflective Type: Non-Reflective
  • Ribbon Color: Black
  • Ribbon Series: R4300
  • Tape Color: White
  • Total Qty per Pack: 1 Roll(s) / Box
  • Trade Name: WorkHorse
  • Adhesive (Y/N): Yes
  • Adhesive Type: Permanent Acrylic
  • Brady Material Number: B-488
  • Continuous & Die-Cut Materials Supported: Continuous Tapes Only
  • Label Properties: Harsh Environment Labels; Heat Resistant Labels; Permanent Adhesive Labels
  • Material: Polyester
  • Material Properties: Autoclavable; Cryogenic storage
  • Resistance Properties: Abrasion-Resistant; Chemical-Resistant; Corrosion-Resistant; Humidity-Resistant; UV-Resistant; Weather-Resistant
  • SAP B-Number: B-488
  • Dimensions (Metric): 19.05 mm W x 6.40 m L
  • Label/Tape Size (in/ft/yd): 0.75 in W x 21 ft L
  • Maximum Service Temperature °C: 145 °C
  • Maximum Service Temperature °F: 293 °F
  • Minimum Application Temperature °C: 10 °C
  • Minimum Application Temperature °F: 50 °F
  • Minimum Service Temperature °C: -40 °C
  • Minimum Service Temperature °F: -40 °F
  • Roll Length (in/ft/yd): 21 ft
  • Roll Length (mm/cm/m): 6.4 m
  • Roll Width (in/ft/yd): 0.75 in
  • Roll Width (mm/cm/m): 19.05 mm
  • Roll/Tape Size (mm/cm/m): 19.05 mm W x 6.4 m L
  • Size - Length (m): 6.40 m
  • Size - Width (mm): 19.05 mm
  • Thickness (in/ft/yd): 0.0037 in
  • Thickness (mm/cm/m): 0.094 mm
  • Vial/Tube Size: 2.0 - 50.0 ml

Regulatory Information

  • Contains CA PROP 65 Substance: No - Does not contain
  • Contains CA PROP 65 Substance: No
  • Contains Heavy Metal(s): No - Does not contain
  • DOT Regulated Product: No = not regulated by DOT
  • EU RoHS Compliance: Pass 2011/65/EU(Pass 2015/863)
  • EU RoHS Compliant: Yes
  • SDS Safety Data Sheet required: No = MSDS/SDS is not required

Categories

Overview

UPC 66282090006
GTiN 00662820900061
Length 6.40 m
Finish Matte
Width 3/4 in
Adhesive Type Permanent Acrylic
Color Black,White
Type Unprinted
Thickness 0.0036 in
Material B-488 Polyester
Applications For Barcode Labeling, Circuit Board Marking, General and Industrial ID, Laboratory ID, Rating Plates, Slide Label
Temperature Rating -40 to 320 F
Family Brand Name Brady
Max Operating Temperature 293 degrees F
Standard Packaging Qty 21 ft Roll
Min Operating Temperature -40 degrees F
Roll Width 0.75 in
Roll Length 21 ft
Used With BMP 21 PLUS Portable Thermal Transfer Label Printer, Idpal Thermal Transfer Handheld Label Maker, Labpal Thermal Transfer Handheld Label Maker
Sub Brand BMP21, WorkHorse
CA Prop65 Warning N
Max Temperature 293 degrees F
Min Temperature -40 degrees F
