BRADY M71EP-172-593 Label,BMP71,B59
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Product image thumbnail 4
$73.59/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Brady
Mfg Catalog # M71EP-172-593
North Coast Part # 1893650

Features

  • Can be used as rating and serial plates using alphanumerics that require nameplate quality
  • Aggressive adhesive and solvent resistance makes them a great replacement for engraved tags
  • UL approved
  • Service temperature of -4 to 212° F (-20 to 100° C)

Specifications

  • Applications: Electrical Labeling; General Identification
  • Brand Name: Brady®
  • Bulk Part: Not a Bulk Part
  • Color: White
  • Compatible Surface Types: High Surface Energy
  • Corner Type: Rounded Corners
  • Enables Industry Compliance: ASTM D 1000; ASTM D 2979; UL Recognized
  • Finish: Gloss
  • For Use with Printer: BMP®71 Label Printer
  • Label/Media Format: Box
  • Pre-Printed Areas on Label: None
  • Primary Noun, Basic Function: Label
  • Print Technology: Thermal Transfer
  • Printer and Label Applications: Electrical; General Identification; Inspection Repair; Rating & Name Plates
  • Recommended Ribbon: M71-R4300
  • Shape: Rectangle
  • Suggested Ribbon Series: R4400; R6000 Halogen Free
  • Total Quantity: 100
  • Trade Name: BMP®71
  • Adhesive Type: Permanent Acrylic - Foam Backed
  • Brady Material Number: B-593
  • Indoor or Outdoor Use: Outdoor Use
  • Label Properties: Heat Resistant Labels; Permanent Adhesive Labels
  • Material: Polyester
  • Material Properties: Raised
  • Overlaminate Included: No
  • SAP B-Number: B-593
  • Average Outdoor Durability: 3 to 5 Years
  • Dimensions: 0.59 in H x 1.77 in W
  • Dimensions (Metric): 14.99 mm H
  • Dimensions 2: 0.59 in H x 1.77 in W
  • Height (in/ft/yd): 0.59 in
  • Height (mm/cm/m): 14.99 mm
  • Label/Tape Size (in/ft/yd): 0.59 in H x 1.77 in W
  • Maximum Service Temperature °C: 100 °C
  • Maximum Service Temperature °F: 212 °F
  • Minimum Service Temperature °C: -20 °C
  • Minimum Service Temperature °F: -4 °F
  • Sign Size-General: 0.59 in x 1.77 in
  • Thickness (in/ft/yd): 0.0256 in
  • Thickness (mm/cm/m): 0.65 mm
  • Vertical Repeat: 1.4375 in
  • Web Width (in/ft/yd): 2.25 in
  • Web Width (mm/cm/m): 57.15 mm
  • Width (in/ft/yd): 1.77 in
  • Width (mm/cm/m): 44.96 mm

Regulatory Information

  • Contains CA PROP 65 Substance: Yes Contains-Label not req.
  • Contains CA PROP 65 Substance: No
  • DOT Regulated Product: No = not regulated by DOT
  • SDS Safety Data Sheet required: No = MSDS/SDS is not required

Overview

UPC 75447357900
GTiN 00754473579005
Finish Gloss
Color White
Thickness 0.025 in
Material Polyester
Shape Rectangle
Family Brand Name Brady?
Indoor Outdoor Outdoor
Max Operating Temperature 212 degrees F
Min Operating Temperature -4 degrees F
CA Prop65 Warning N
Width 1.77 in
Height 0.59 in
Max Temperature 212 degrees F
Min Temperature -4 degrees F
