BRADY WMS-105-319 Wire Mkr,BrdMkr,B
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Usually ships within 6 to 8 Days
Already a Customer? Log in to view your pricing
Manufacturer Brady
Mfg Catalog # WMS-105-319
North Coast Part # 211214


  • Designed for use in manufacturing, construction and maintenance to identify electrical wires and cables
  • Designed for dot-matrix printing, but can also be printed with a typewriter or permanent marking pen
  • RoHS Compatibility Pass 2011/65/EU


  • Material Number: B-319
  • Catalog Page #: 96
  • Diameter as Supplied: 0.105 in
  • Dimensions: 0.35 in H x 0.5 in W
  • UOM: Roll of 500 Each
  • Finish: Matte
  • Maximum Service Temperature °F: 266 °F
  • Maximum Wire Diameter: 0.13 in
  • Maximum Wire Gauge: 12 AWG
  • Minimum Service Temperature °F: -85 °F
  • Minimum Wire Diameter: 0.075 in
  • Minimum Wire Gauge: 18 AWG
  • Printable Sides: Single-Side Printable
  • Product Number: 32581
  • UPC: 662820325819
  • Quantity per Roll: 500
  • Quantity per Row: 1
  • Roll Width: 0.5 in
  • Shrink Ratio: Non-Shrinking
  • Sleeve Size: 0.105 in Dia
  • Sleeve Size(m): 2.67 mm Dia
  • Thickness: 0.0059 in
  • Trade Name: BradyMarker™
  • Applications: Cable & Wire Marking, Panel Labeling
  • Color: White
  • For Use with Printer: BradyMarker® XC Plus, I.D. PRO® Plus Mobile Label Printer, LS2000 Labeling System
  • Label/Media Format: Roll
  • Label Properties: Heat Shrink Sleeves
  • Material: Polyolefin
  • Print Technology: Dot Matrix
  • Resistance Properties: Chemical-Resistant, Corrosion-Resistant, Humidity-Resistant, Smear-Resistant, UV-Resistant, Weather-Resistant
  • Suggested Ribbon Series: R2000, R5000

Related Products

  • QS
  • PMS-HG-1


UPC 66282032581
Item Long Description The B-319 material is a non-shrinkable polyolefin wiremarker sleeve material that demonstrates outstanding legend permanence and smudge resistance.
GTiN 00662820325819
Finish Matte
Width 0.5 in
Color White
Type Wire Marker
Diameter 0.105 in
Thickness 0.005 in
Material Polyolefin
Shrink Ratio Non-Shrinking
Applications Cable & Wire Marking; Panel Labeling
Height 0.35 in
Wire Size 0.075-0.13 in
Family Brand Name Brady
Qty per Row 1
Max Operating Temperature 266 degrees F
Min Operating Temperature -85 degrees F
Roll Width 0.5 in
Sub Brand BradyMarker Series
CA Prop65 Warning No - Does Not Contain
