Broan 1671F 70 CFM 6 Sones Ventilation System Finish Pack
$37.18/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Broan
Mfg Catalog # 1671F
North Coast Part # 339367

Features

  • Housings and finishes (motor assembly and grille) sold separately.
  • The finish kit includes the motor plate, motor, wheel and grille.
  • 50/70 CFM at 2.5/4.0 Sones reduces humidity or odors in bathrooms up to 45/65 square feet to help make your surroundings more comfortable
  • Fan has a galvanized steel housing with double-strength mounting flanges and can be Ceiling or Wall mounted, ducted vertically (horizontally) to a roof cap (wall cap)
  • cULus Listed for use over tub or shower with a GFCI circuit so you can control ventilation by locating your fan exactly where you need it the most
  • Combine with model 1776H Rough-In Housing Kit

Specifications

  • CFM: 70
  • Recommended Room Size (Sq. Ft.): 65
  • Sones: 6.0
  • Room Side Installation: No
  • Duct Diameter: 3"
  • Housing Height: 3-5/8"
  • Housing Length: 7-1/4"
  • Housing Width: 7-1/2"
  • Grille Length: 9"
  • Rated Amps: 1.15
  • Warranty: 1 year limited
  • Nightlight: No
  • Grille Width: 9-1/4"
  • Minimum Construction Space Required: 2" x 6"
  • Motor Engineered for Continuous Operation: No
  • Radiation Damper Available: No
  • Voltage: 120

Overview

UPC 02671502328
GTiN 00026715023288
Type Project Finish Pack
Family Brand Name Broan-Nutone
Warranty Length 1 yr
Voltage 120 Volt
Amperage 1.15 Amp
Grille Width 9-1/4 in
Duct Size 3 in
Grille Length 9 in
Airflow Rate 70 CFM
Housing Height 3-5/8 in
Housing Width 7-1/2 in
