BROAN QTR050F 50 CFM, 0.4 Sones, Fa
Product image thumbnail 0
Product image thumbnail 1
$99.52/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Broan
Mfg Catalog # QTR050F
North Coast Part # 267548

Overview

To simplify installation, Project Packs are ideal for Builders and Contractors. When drywall work and painting is complete, the fan components needed to finish the job are available in single packs under separate model numbers.

  • This finish kit includes the motor plate, motor, wheel and grille
  • Available in Project Packs only to simplify installation for Builders & Contractors
  • 50 CFM; Very Quiet operation 0.4 Sones
  • 4" ducting; fits 2 x 8 construction
  • Motor engineered for continuous operation
  • UL Listed for use over tub/shower with GFCI circuit
  • Use with QTXR000HF housing pack to complete the installation

Specifications

  • Humidity Sensing: No
  • Rated Sones - Vertical: N/A
  • Lighting Type: No Light
  • Motor engineered for continuous operation: Yes
  • Wall Installation: No
  • HVI Certified: Yes
  • Rated Watts: 26.8
  • CFM @ 0.25": 28
  • Color: White
  • Grille Finish: White Polymeric
  • Watts @ 0.25": 26.6
  • Globe Glass Color: N/A
  • Light Bulb Quantity: 0
  • Sones: 0.4
  • CSA: No
  • Material: Polymeric
  • Housing Width: N/A
  • Light Bulbs Included: No
  • Housing Height: N/A
  • Nightlight: No
  • Duct Size: 4"
  • Warranty: 3 Years
  • Ceiling Installation: Yes
  • Housing Dimension LxWxH: N/A
  • Minimum construction space required: 2x8
  • Duct Direction: Horizontal
  • CFM @ 0.125": N/A
  • Product Weight: 7.8 lbs
  • Rated Amps: 0.2
  • Baths up to () Sq Ft: 45
  • Grille Width: 14"
  • Light Bulb Wattage: N/A
  • Watts @ 0.1": 26.8
  • ENERGY STARĀ® qualified: No
  • Project Pack: Yes
  • Grille Length: 13"
  • Housing Length: N/A
  • UL Listed for use over bathtubs or showers when connected to a GFCI circuit: Yes
  • CFM @ 0.10": 50
  • Heater wattage: N/A
  • cUL Listed: No

Resources

Overview

UPC 02671517002
GTiN 00026715170029
Finish White Polymeric
Warranty Length 3 yr
Color White
Type QTR Series Project Finish Pack
Material Polymeric
Applications For QTR050 Fan
Weight 7.8 lb
Standard HVI 2100 Certified,UL Listed For Use Over Bathtubs And Showers When Connected To A GFCI Protected Branch Circuit (Ceiling Mount Only)
Wattage 26.8 Watt
Family Brand Name Broan-Nutone
Sones 0.4 Sone
Energy Saver No
Amperage 0.2 Amp
Grille Width 14 in
Duct Size 4 in
Grille Length 13 in
Grille Material Polymeric
