Broan QTRE100S 100 CFM Humidity Sensing Fan
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$348.41/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Broan
Mfg Catalog # QTRE100S
North Coast Part # 428769

Overview

  • Nearly silent operation 1.5 Sones
  • 100 CFM
  • Sensaire technology detects the rapid rise in humidity over time
  • Integrated 20 minute auto shut-off timer
  • ENERGY STAR Qualified
  • Hanger bars for Easy, Fast and Universal installation in all types of construction
  • UL Listed for use over bathtubs and showers when connected to a GFCI protected branch circuit
  • Housing Dimension: 10-1/2" x 11-3/8" x 7-5/8"- Fits 2" x 8" construction
  • Grille Dimension: 13" x 13-3/4"

Specifications

  • Globe Glass Color: N/A
  • Motor engineered for continuous operation: Yes
  • Housing Height: 7-5/8"
  • Minimum construction space required: 2x8
  • cUL Listed: No
  • Light Bulb Quantity: 0
  • Rated Watts: 36.3
  • CFM @ 0.10": 100
  • CSA: No
  • Project Pack: No
  • Duct Size: 4"
  • CFM @ 0.25": 81
  • Watts @ 0.25": 36.2
  • Housing Dimension LxWxH: 10-1/2" x 11-3/8" x 7-5/8"
  • Material: Polymeric
  • Grille Finish: White Polymeric
  • Humidity Sensing: Yes
  • Warranty: 3 Years
  • HVI Certified: Yes
  • Light Bulbs Included: No
  • Ceiling Installation: Yes
  • Lighting Type: No Light
  • Wall Installation: No
  • Grille Width: 13-3/4"
  • Sones: 1.5
  • Watts @ 0.1": 36.3
  • Baths up to () Sq Ft: 90
  • ENERGY STARĀ® qualified: Yes
  • Grille Length: 13"
  • Duct Direction: Horizontal
  • Nightlight: No
  • CFM @ 0.125": N/A
  • Color: White
  • Light Bulb Wattage: N/A
  • Rated Amps: 0.3
  • Housing Width: 11-3/8"
  • Heater wattage: N/A
  • UL Listed for use over bathtubs or showers when connected to a GFCI circuit: Yes
  • Housing Length: 10-1/2"
  • Product Weight: 12.6 lbs
  • Rated Sones - Vertical: N/A

Video Links

Resources

Overview

GTiN 00026715176298
Length 10-1/2 in
Finish White Polymeric
Warranty Length 3 yr
Width 11-3/8 in
Color White
Type Automatic Humidity Sensing Ceiling Mount Fan
Material Polymeric
Applications For Bathrooms Up To 90 SQ-FT
Height 7-5/8 in
Weight 12.6 lb
Standard Energy Star Certified,HVI 2100 Certified,UL Listed For Use Over Bathtubs And Showers When Connected To A GFCI Protected Branch Circuit (Ceiling Mount Only)
Wattage 36.3 Watt
Family Brand Name Broan-Nutone
Sones 1.5 Sone
Energy Saver Yes
Amperage 0.3 Amp
Grille Width 13-3/4 in
Duct Size 4 in
Grille Length 13 in
Grille Material Polymeric
Product UPC 02671517629
