Broan QTX110HL 14.6 Amp 120 Volt 110 CFM 0.9 Sones 1500 W 20 x 15 Inch Grille Ventilation Fan/Heater with Lamp
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Already a Customer? Log in to view your pricing
Manufacturer Broan
Mfg Catalog # QTX110HL
North Coast Part # 213159


  • Efficient PowerHeatâ„¢ heater design
  • Choice of standard A19 base (2, 60 watt) lighting (bulbs not included) or energy efficient 36 watt GU24 fluorescent (bulbs included)
  • Fan motor is engineered for continuous operation
  • HVI Certified • Type IC
  • Requires a dedicated 20 amp circuit
  • Switches sold separately
  • 7 watt night-light bulb not included


  • CFM: 110
  • Recommended Room Size (Sq. Ft.): 105
  • Sones: 1.2
  • Light Bulb Wattage: 120 (2-60W)
  • Recommended Light Bulb Type: A19
  • Light Bulb Quantity: 2
  • Room Side Installation: No
  • Duct Diameter: 6"
  • Housing Height: 7-5/8"
  • Housing Length: 17-5/8"
  • Housing Width: 11-3/8"
  • Grille Length: 20"
  • Rated Amps: 14.6
  • Watts: 42.8
  • Warranty: 3 year limited
  • Lighting Type: Incandescent
  • Light Bulbs Included: No
  • Nightlight: No
  • Grille Width: 15"
  • Minimum Construction Space Required: 2" x 8"
  • Motor Engineered for Continuous Operation: No
  • Radiation Damper Available: No
  • Voltage: 120
  • UL Listed: No


UPC 02671516389
Item Long Description You could wait 15 minutes for your central heating system to take the chill from your bathroom, all while it heats every other room in the house. Or, you could select instant heat when its needed with the QTX line. Powerful heating, light and ventilation are available at the touch of a switch. And with our PowerHeat design, youre assured that the energy converted to heat is efficiently delivered back to you.
GTiN 00026715163892
Warranty Length 3 yr
Voltage 120 Volt
Type Fan With Light And Heater
Applications For Bathrooms Up To 100 SQ-FT
Standard HVI 2100 Certified,UL Listed
Wattage 2-60 Watt
Family Brand Name Broan-Nutone
Sones 1.2 Sone
Light Type Incandescent
Bulb Included No
Amperage 14.6 Amp
Grille Width 15 in
Duct Size 6 in
Grille Length 20 in
Airflow Rate 110 CFM
Housing Height 7-5/8 in
Housing Width 11-3/8 in
Grille Material Polymeric
