Burndy BIBS2506MT 250 MCM 10 AWG 6-Port Unitap with Mount
Product image thumbnail 0
Product image thumbnail 1
$150.30/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Burndy
Mfg Catalog # BIBS2506MT
North Coast Part # 68649

Specifications

General

  • Hex Key: 5/16
  • Insulation: Y
  • Insulation Type: Plastisol
  • Material: Aluminum
  • Number Of Ports: 6
  • Physical Attribute - Number of Screws: 8
  • Physical Attribute - Screw Type: Allen
  • Plated: N
  • Plating Type: Unplated
  • Temperature Rating: 194
  • Trade Name: UNITAP™
  • UPC: 781810252925
  • UPC 12 Digit: 7818102529255

Dimensions

  • Dimension - Height inch: 2.63 in
  • Dimension - L Length Overall mm: 194 mm
  • Dimension - Length Overall inch: 7.65 in
  • Dimension - Width inch: 1.95 in
  • Dimension - Width mm: 50 mm

Electrical Ratings

  • Rating - Minimum Voltage: 600

Conductor Related

  • Conductor - AL Str Size Range: 10 - 250 Str
  • Conductor - Copper Str Size Range: 10 - 250 Str

Certifications and Compliance

  • Certification - CSA Approved: Yes
  • Certification - ETL: No
  • Certification - UL Listed Direct Burial: No
  • Certification - UL Recognized: No
  • Certification - cULus: No
  • Industry Standard(s): UL467
  • Standards - Industry Standards Met: UL467
  • Standards - RoHS Compliance Status: CM
  • UL Listed: Yes

Logistics

  • Minimum Pack Quantity: 5

Conductor Type

  • AL C Str-Size
  • CU C Str-Size

Overview

UPC 78181025292
GTiN 00781810252925
Family Brand Name Hubbell
Length 7.65 in
Width 1.95 in
Insulation Type Plastisol
Material Aluminum
Height 2.63 in
Plating Type Unplated
Plated? No
CSA Yes
