Burndy GG151 1 Inch Braid to 1 Inch Threaded Copper Alloy Grounding Connector

Specifications

General

• Installation Torque Recommended in-lb: 240 LBS/in
• Material: Copper Alloy, Cast
• Material Type - Screw: DURIUM™ Silicon Bronze
• Plated: N
• Plating Type: Unplated
• U Bolt Type: 244
• UPC: 781810260043
• UPC 12 Digit: 7818102600433

Dimensions

• Dimension - B Length inch: 1.31 in
• Dimension - Height fraction: 3-3/8 in
• Dimension - Height inch: 3.38 in
• Dimension - Width inch: 2.63 in
• Dimension - Width mm: 67 mm

Conductor Related

• Conductor - Copper Tube Std Size: 1 IPS IPS
• Conductor - Rod Size: 1 1/8 in;1 1/4 in

Certifications and Compliance

• Certification - CSA Approved: No
• Certification - ETL: No
• Certification - UL Listed Direct Burial: Yes
• Certification - UL Recognized: No
• Certification - cULus: No
• Industry Standard(s): UL467
• Standards - Industry Standards Met: UL467
• Standards - RoHS Compliance Status: EX
• UL Listed: No

Logistics

• Minimum Pack Quantity: 16
