Burndy NA18A2N 7.50 Inch Length Terminal
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$111.62/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Burndy
Mfg Catalog # NA18A2N
North Coast Part # 827130

Specifications

  • Clamping Element Design: Body and Cap
  • Conductor - AL Tube Std Size: 2 IPS
  • Conductor - AL Tube Std Size Range: 2 IPS
  • Conductor - Connection Combination: Tube to Flat
  • Conductor - Copper Tube Std Size: 2 IPS IPS
  • Conductor - Copper Tube Std Size Range: 2 IPS IPS
  • Country of Origin: US
  • Dimension - B Length fraction: 4-1/4 in
  • Dimension - B Length inch: 4.25 in
  • Dimension - D inch: 3.00 in
  • Dimension - F Width Center to Center inch: 1.75 in
  • Dimension - G inch: 2.05 in
  • Dimension - Height fraction: 4-1/2
  • Dimension - Height inch: 4.47 in
  • Dimension - Hole Size fraction: 9/16
  • Dimension - L Length Overall mm: 191 mm
  • Dimension - Length Overall inch: 7.50 in
  • Dimension - N inch: 0.63 in
  • Dimension - Pad Width inch: 2.75 in
  • Dimension - Width fraction: 4-1/2 in
  • Dimension - Width inch: 4.50 in
  • Dimension - Width mm: 114 mm
  • Each - Height: 0.000 in
  • Each - Length: 0.000 in
  • Each - Width: 0.000 in
  • Installation Torque Recommended in-lb: 480 LBS/in
  • One Wrench Installation: Y
  • Physical Attribute - Number of Holes: 2
  • Physical Attribute - Pad Alignment: Offset
  • Physical Attribute - Pad Configuration: 2.75 x 3 - 2 holes
  • Physical Attribute - Pad Orientation: Straight
  • Plated: N
  • Plating Type: Unplated
  • Product Type: Mechanical
  • Rating - KVA: 230 kV
  • Show Add To ProjectList: Yes
  • Standards - RoHS Compliance Status: CM

Certifications

  • CSA Approved: No
  • cULus: No
  • ETL: No
  • UL Recognized: No

Overview

UPC 78181000375
Family Brand Name Hubbell
Item Long Description Cu Alloy Terminal, 2 IPS Al or Cu, 230 kV, 2 Pad Holes, 1.75 IN Spacing, 7.50 IN L, 4.50 IN W, Bolted, Tube to Flat, 0.56 IN Hole Dia.
Length 7.50 in
Width 4.50 in
Material Aluminum Alloy
Height 4.47 in
Connection Type Terminal
Plating Type Unplated
Plated? No
CSA No
