BUR T146 RING- 20- 14 AWG-UNIN, 0.
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$33.51/c (100 ea)
Usually ships within 11 to 17 Days
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Burndy
Mfg Catalog # T146
North Coast Part # 157423

Features

  • The Type T Uninsulated Terminals Are Constructed Of Pure Electrolytic Copper, Designed With A Long Brazed Seam Barrel, Standard Neck, Deep V Groove Inner Serrations And Electro-Tin Plated, The Terminals Are Ideal For Control Wiring And Other Standard Duty Applications, The Ring Tongue Provides A Secure Termination Under The Screw Head That Cannot Be Removed Without The Complete Removal Of The Screw, Two Or More Terminals Can Easily Be Stacked On A Common Stud, Constructed Of Pure Electrolytic Copper: Provides Maximum Conductivity, Low Resistance And Ductility For Excellent Crimp Forming Properties, Long Brazed Seam Barrel And Deep V Groove Inner Serrations: Provides Optimum Conductivity Reliability And Holding Power After Crimping, Electro-Tin Plated: Provides Durable Long-Lasting Corrosion Resistance, Wire Range Is Clearly Marked On Terminal: Provides Easy Identification, Inspection Hole: Provides An Easy Visual Check Of Wire Insertion, Long Neck Terminal: Permits Easy Bending And Stacking Of Several Terminals On A Common Stud, Tape Mounted Catalog Number: YAD14-6M, Bulk Catalog Number: YAD14-6, Wire Insulation Grip: No, Wire Strip Length: 9/32 IN, Installation Tool: Non-Ratchet: Y10D, Y10-22 Tool, Ratchet: Y8MRB-1, MR20, MR8G98 Tool, Finish: Electro-Tin Plated

Specifications

  • Country of Origin: US
  • Dimension - B Length fraction: 13/50 in
  • Dimension - B Length inch: 0.26 in
  • Dimension - Diameter Max Size inch: 0.08 in
  • Dimension - Hole Size fraction: 3/20
  • Dimension - Hole Size inch: 0.15 in
  • Dimension - L Length Overall mm: 17
  • Dimension - Length Overall inch: 0.66 in
  • Dimension - Pad Width inch: 0.25 in
  • Dimension - Strip Length inch: 9/32
  • Dimension - Stud Size inch: #4 - #6
  • Dimension - Z inch: 0.28 in
  • Each - Height: 0.000 in
  • Each - Length: 0.000 in
  • Each - Width: 0.000 in
  • Feature - Barrel Type: Long
  • Industry Standard(s): UL467
  • Physical Attribute - Number of Holes: 1
  • Physical Attribute - Tongue Type: Ring
  • Plated: Y
  • Plating Type: Tin
  • Product Type: Compression
  • Show Add To ProjectList: Yes
  • Standards - Industry Standards Met: UL467
  • Standards - RoHS Compliance Status: CM
  • Trade Name: HYLUG™
  • Sub Brand: HYLUG
  • IGS 3D Model Asset Reference URL 2: https://hubbellcdn.com/igs/T146_MODEL-IGES.zip
  • PDF 3D Model Asset Reference URL 1: https://hubbellcdn.com/PDF3DFile/T146_MODEL-PDF.pdf
  • STEP 3D Model Asset Reference URL 3: https://hubbellcdn.com/step3dfile/T146_MODEL-STEP.zip

Certifications

  • CSA Approved: Yes
  • cULus: No
  • ETL: No
  • UL Recognized: No
  • EU RoHS Indicator: Yes

Overview

UPC 78181072236
Item Long Description Uninsulated Compression Terminal,Ring Tongue, 4-6, 0.67 in L, Constructed of pure electrolytic copper.
GTiN 00781810722367
Type Ring Tongue
Material Copper
Stud Size 0.112-0.138 in
Applications For Control Wiring And Other Standard Duty Applications
Cable Size 20 - 14 AWG
Family Brand Name Burndy
Sub Brand HYLUG
Length 0.66 in
Connection Type Terminal
Plating Type Tin
Plated? Yes
CSA Yes
